Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 147mm -
Fork DVO Diamond
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
DVO Diamond D1 160mm, 29”, 110x15
Rear Shock
DVO Topaz T3 Air, 210 x 55
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM PG 1230 11-50T
Crank
SRAM NX Eagle, DUB spindle, 32t Steel Ring (170mm for S/M, 175mm for L/XL)
Bottom Bracket
Threaded (73mm English threaded)
Chain
SRAM NX Eagle
Wheels
Rims
Ibis S35 Aluminum / 29" / Ibis Hubs
Tires
Maxxis Assegai 29” x 2.5” WT, EXO+ casing, 120tpi
Brakes
Brakes
SRAM Guide T 4p
Disk Rotors
SRAM Centerline 200/180 rotors
Cockpit
Stem
Ibis 31.8mm (40, 50, 60, 70, 80, 90mm)
Handlebar
Ibis 780mm Alloy
Grips
Lizard Skins Charger Evo
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado Pro 142mm width
Seatpost
KS Rage-i Dropper (125, 150 or 170mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.35 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 752 mm | 783 mm | 804 mm | 829 mm |
| Rake | 43 mm | 43 mm | 43 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Stack | 619 mm | 626 mm | 635 mm | 648 mm |
| Reach | 437 mm | 464 mm | 481 mm | 501 mm |
| Top Tube Length | 579 mm | 609 mm | 638 mm | 661 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 355 mm | 380 mm | 419 mm | 470 mm |
| Head Tube Angle | 64.9 ° | 64.9 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1191 mm | 1222 mm | 1243 mm | 1268 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 711 mm | 756 mm | 756 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ripmo AF NX is part of the Ibis Ripmo model. 69 bikes variations carry this model name so far. You can easily view all of the Ibis Ripmo bikes models from 2020, here.
Model range prices
Ibis Ripmo AF NX 2020 is the cheapest bike model and costs 2999$. Ibis Ripmo XX1 AXS 2020 is the most expensive one and costs 10999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2020 and its price was 2999$. Comparing the average cost of a Trail bike to this one, you will see that Ripmo AF NX price is 8.58% higher.
Ripmo AF NX components
Fork
The DVO Diamond is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is DVO Topaz T3 Air, with a travel distance of 147mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Ripmo AF NX are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Ibis Ripmo AF NX has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Ibis Ripmo AF NX bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Ripmo AF NX. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
