Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 145mm -
Fork Fox Performance Float 36
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX Float 36 Performance Series, Boost
Rear Shock
FOX Float Performance Series, DPX2 with EVOL, 210mm x 55mm
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM PG-1130, 11-42 tooth, 11-speed
Crank
SRAM NX
Bottom Bracket
73mm English threaded
Chain
SRAM PC-1110
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Ibis, 36 tooth 4 pawl ratchet, 10° engagement, Front: Boost, 15mm x 110mm, Rear: Boost, 12mm x 148mm
Rear Hub
Ibis, 36 tooth 4 pawl ratchet, 10° engagement, Front: Boost, 15mm x 110mm, Rear: Boost, 12mm x 148mm
Rims
Ibis 938, alloy, 34mm inner width, 38mm outer width, 32 hole, tubeless ready
Spokes
Sapim CX-Ray
Tires
Front: Maxxis Minion DHF WT, 2.5”, Rear: Maxxis Aggressor WT, 2.5”
Brakes
Brakes
SRAM Level with Centerline 180mm rotors
Brake Levers
SRAM Level
Cockpit
Stem
Ibis, 50mm-90mm length options, 31.8mm clamp
Handlebar
Ibis, alloy, 780mm width
Grips
Lizard Skins Logo
Headset
Cane Creek 40, ZS44/ZS56
Seat
Saddle
Ibis custom saddle, chromoly rails
Seatpost
KS LEV-Si, 100mm, 125mm, 150mm drop options, KS Integra, 175mm drop option (+$80)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Stack | 619.6 mm | 630.6 mm | 635.6 mm | 648.6 mm |
| Reach | 437.6 mm | 452.6 mm | 477.6 mm | 499.6 mm |
| Top Tube Length | 579.6 mm | 608.6 mm | 638.6 mm | 661.6 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 355.6 mm | 368.3 mm | 419.1 mm | 469.9 mm |
| Head Tube Angle | 65.9 ° | 65.9 ° | 65.9 ° | 65.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1183 mm | 1203 mm | 1234 mm | 1262 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 711 mm | 756 mm | 756 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Ripmo NX completes the Ibis Ripmo model. There are 69 bikes that carry this model name. Take a sneak peek at all Ibis Ripmo bikes models from 2018, by clicking here.
Model range prices
Ibis Ripmo NX 2018 is the most economical model, with a starting price of 6306$. Ibis Ripmo XX1 Eagle 2018 on the other hand costs 9669$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6306$. If we compare this with the average Trail bike cost we notice that the price is 128.31% higher.
Ripmo NX components
Fork
The Ripmo NX comes factory-installed with the Fox Performance Float 36 fork. This has a travel range of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float Performance Series model, with a travel of 145mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Ripmo NX bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Ripmo NX comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Ibis model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
