Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 145mm -
Fork Fox Performance Float 36
-
Groupset X01, X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber Monocoque
Suspension Fork
Fox Float 36 Performance Series 160mm, 29”, 110x15
Rear Shock
Fox Float Performance Series, DPX2 with EVOL, 210 x 55
Drivetrain
Rear Derailleur
SRAM Eagle X01 12 Speed
Shift Levers
SRAM Eagle X01 12 Speed
Cassette
SRAM XG 1295 EAGLE 10-50T
Crank
SRAM X01 Eagle 175, DUB spindle, 32t Alloy Ring
Bottom Bracket
SRAM DUB BSA
Chain
SRAM X01 EAGLE Powerlock 12 speed chain
Wheels
Rims
Ibis 938 Alloy, Ibis Hubs
Tires
Maxxis Minion DHF WT Front / Aggressor WT 29” x 2.5” Rear
Brakes
Brakes
Shimano XT M8000 4 piston
Disk Rotors
Shimano SM-RT86 180
Cockpit
Stem
Thomson Elite X4 Stem (40, 50, 60, 70, 80, 90, 100, 110)
Handlebar
Ibis 800mm Carbon (10 or 30mm rise)
Grips
Lizard Skins Charger Evo
Headset
Cane Creek 40 ZS44/ZS56
Seat
Saddle
WTB Silverado 142
Seatpost
Bike Yoke Revive Dropper (125, 160 or 185mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Trail | 118 mm | 118 mm | 118 mm | 118 mm |
| Stack | 615 mm | 622 mm | 631 mm | 644 mm |
| Reach | 433 mm | 448 mm | 473 mm | 495 mm |
| Top Tube Length | 575 mm | 605 mm | 634 mm | 657 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 368 mm | 368 mm | 418 mm | 470 mm |
| Head Tube Angle | 65.9 ° | 65.9 ° | 65.9 ° | 65.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1179 mm | 1197 mm | 1222 mm | 1251 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 707 mm | 752 mm | 752 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ripmo X01 Eagle belongs to the Ibis Ripmo model. Ibis launched 69 bikes of this model so far. Take a sneak peek at all Ibis Ripmo bikes models from 2019, by clicking here.
Model range prices
Ibis Ripmo NX Eagle 2019 is the most affordable bike of this model and has a price of 4199$. On the other hand, Ibis Ripmo XX1 Eagle 2019, is the most expensive and costs 9599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6999$. Comparing the average cost of a Trail bike to this one, you will see that Ripmo X01 Eagle price is 153.4% more expensive.
Overview of components
Fork
The Ripmo X01 Eagle comes factory-installed with the Fox Performance Float 36 fork. This has a travel range of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Ibis Ripmo X01 Eagle bike has the Fox Float Performance Series model installed, and has a travel of 145mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Ibis Ripmo X01 Eagle 2019, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ripmo X01 Eagle has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Ibis Ripmo X01 Eagle includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
