Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 130mm -
Fork RockShox Revelation RC
-
Groupset GX, NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Revelation, Solo Air, 15mm quick release thru axle, 110mm x 15mm
Rear Shock
RockShox Monarch RL, 200mm x 51mm
Drivetrain
Rear Derailleur
SRAM GX, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM PG1130, 11-speed, 11-42 tooth
Crank
Race Face Aeffect, 170mm
Bottom Bracket
Race Face, BB92
Chain
SRAM PC1110, 11-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: 32 hole Intense Tuned, 110mm x 15mm, Rear: 32 hole Intense Tuned, 148mm x 12mm, boost, XD driver
Rear Hub
Front: 32 hole Intense Tuned, 110mm x 15mm, Rear: 32 hole Intense Tuned, 148mm x 12mm, boost, XD driver
Rims
Race Face AR 40
Spokes
DT Swiss Champion
Tires
Front: Maxxis Rekon, 27.5x2.8“, EXO, TR, Front: Maxxis Rekon, 27.5x2.8“, EXO, TR
Brakes
Brakes
Shimano M500, 180mm front, 160mm rear
Brake Levers
Shimano M500
Cockpit
Stem
Intense, 45mm
Handlebar
Intense Recon, 780mm wide
Grips
Intense dual density lock-on
Headset
Cane Creek 40, alloy cartridge, 25mm of spacers
Seat
Saddle
WTB Silverado Sport with steel rails
Seatpost
Race Face Aeffect, 150mm of travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.51 mm | 1.46 mm | 1.39 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Stack | 619 mm | 627 mm | 639 mm | 644 mm |
| Reach | 393 mm | 415 mm | 437 mm | 462 mm |
| Top Tube Length | 572 mm | 598 mm | 623 mm | 650 |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 433 mm | 458 mm | 484 mm | 509 mm |
| Head Tube Angle | 76.25 ° | 76.25 ° | 76.25 ° | 76.25 ° |
| Head Tube Length | 94 mm | 102 mm | 114 mm | 119 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1145 mm | 1171 mm | 1198 mm | 1224 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 800 mm | 804 mm | 809 mm | 812 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ACV Foundation is part of the Intense Acv model. 5 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Intense ACV Foundation 2018 has a starting price of 2999$. Intense ACV Pro 2018 on the other hand is the most expensive at 4699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Intense released this model in 2018, its price was 2999$. In conclusion, this bike price is 8.58% higher than the price of the average Trail bike.
ACV Foundation components
Fork
The ACV Foundation comes factory-installed with the RockShox Revelation RC fork. This has a travel range of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch RL model, with a travel of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the ACV Foundation model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The ACV Foundation has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
