Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 130mm -
Fork RockShox Revelation RC
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ACV 27+ Monocoque UD Carbon Front and Rear Triangle, alloy Top Link, Internal Derailleur Routing, Integrated protector, w/ 148 x12 mm spacing, 115 -130 mm travel
Suspension Fork
Rock Shox Revelation RC 27.5+, Solo Air, 150mm, Boost 110x15mm
Rear Shock
Rock Shox Monarch RL, 200x51mm
Drivetrain
Rear Derailleur
SRAM NX Eagle 12speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle 12speed Trigger
Cassette
SRAM NX Eagle PG1230 12speed, 11-50T
Crank
SRAM NX DUB™ Eagle 170mm, 32T
Bottom Bracket
SRAM PF DUB™
Chain
SRAM NX Eagle 12speed
Chain Guide
N/A
Wheels
Front Hub
Intense Tuned, 6 Bolt, 110x15mm, 32 Hole Front / 148x12mm, 32 Hole Rear
Rear Hub
Intense Tuned, 6 Bolt, 110x15mm, 32 Hole Front / 148x12mm, 32 Hole Rear
Rims
Race Face AR 40, 27.5"
Spokes
DT Swiss Champion
Tires
Maxxis 27.5x2.80+ Rekon F60 DC/EXO/TR
Brakes
Brakes
Shimano M500 6 Bolt 180mm FR / 160mm RR
Cockpit
Stem
Intense 45mm, 31.8 mm diameter
Handlebar
Intense Recon 780mm Alloy, 31.8 mm diameter
Grips
Intense Lock-On
Headset
Intense Tapered
Seat
Saddle
WTB Silverado Sport w/ Steel Rails
Seatpost
Intense 31.6mm, 150mm Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.51 mm | 1.46 mm | 1.39 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Stack | 619 mm | 627 mm | 639 mm | 644 mm |
| Reach | 393 mm | 415 mm | 437 mm | 462 mm |
| Top Tube Length | 572 mm | 598 mm | 623 mm | 650 |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 433 mm | 458 mm | 484 mm | 509 mm |
| Head Tube Angle | 66.3 ° | 66.3 ° | 66.3 ° | 66.3 ° |
| Head Tube Length | 94 mm | 102 mm | 114 mm | 119 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1145 mm | 1171 mm | 1198 mm | 1224 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 800 mm | 804 mm | 809 mm | 812 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ACV FOUNDATION is part of the Intense Acv model. There are 5 bikes that carry this model name. Take a sneak peek at all Intense Acv bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Intense ACV FOUNDATION 2019 has a starting price of 3299$. Intense ACV PRO 2019 on the other hand is the most expensive at 4699$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Intense ACV FOUNDATION price was 3299$. If we compare this with the average Trail bike cost we notice that the price is 19.44% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The ACV FOUNDATION comes factory-installed with the RockShox Revelation RC fork. This has a travel range of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Intense ACV FOUNDATION bike has the Rock Shox Monarch RL model installed, and has a travel of 130mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Intense ACV FOUNDATION 2019, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Intense ACV FOUNDATION has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Intense ACV FOUNDATION comes with a dropper post. Therefore, climbing or descending will be a breeze.
