Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 155mm -
Fork RockShox Lyrik
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
165cm - 177cm
LG
175cm - 185cm
XL
180cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbine 29” Optimized Layup Monocoque UD Carbon Front and Rear Triangle, Carbon top link, Ti hardware, internal shift, dropper post and brake routing. ISCG05 mounts, flack guard armour, 155mm travel
Suspension Fork
Rock Shox Lyrik RCT3 29, Solo Air, 160mm, Boost 110x15mm
Rear Shock
Rock Shox Super Deluxe RC3, 230x60mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle 12speed Trigger, Black
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle 12speed Trigger, Black
Cassette
SRAM XG1295 X01 Eagle 12speed, 10-50T
Crank
Tru Vativ Descendant Carbon Eagle DUB 175mm, 32T
Bottom Bracket
SRAM Pressfit DUB BB92
Chain
SRAM GX Eagle 12speed
Wheels
Front Hub
DT Swiss 350 Classic, Centerlock, 110x15mm Front, 148x12mm, XD rear Centerlock
Rear Hub
DT Swiss 350 Classic, Centerlock, 110x15mm Front, 148x12mm, XD rear Centerlock
Rims
E13 TRS RACE 29" Carbon, 28 Hole, 31mm Channel
Spokes
DT Swiss Competition 2.0/1.8/2.0MM Black
Tires
Maxxis 29x2.40 Minion DHR II 60TPI EXO/TR
Brakes
Brakes
Shimano XT M8020 Hydraulic Disk 180mm Front & 180mm Rear
Cockpit
Stem
Intense Recon ELITE 40mm
Handlebar
Intense Recon 780mm Carbon
Grips
Intense Dual Lock-On
Headset
Cane Creek 40 Series, ZS44/EC49.40
Seat
Saddle
Fabric Scoop Radius Elite w/ Cr-Mo Rails
Seatpost
Fox Transfer 31.6mm, 150mm Dropper (MD, LG, XL), 125mm Dropper (SM)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 736 mm | 760 mm | 788 mm | 808 mm |
| Rake | 41 mm | 41 mm | 41 mm | 41 mm |
| Trail | 126 mm | 126 mm | 126 mm | 126 mm |
| Stack | 618 mm | 626 mm | 634 mm | 643 mm |
| Reach | 412 mm | 433 mm | 457 mm | 473 mm |
| Top Tube Length | 605 mm | 629 mm | 657 mm | 677 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 385 mm | 418 mm | 448 mm | 483 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 92 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1183 mm | 1207 mm | 1235 mm | 1255 mm |
| Standover Height | 832 mm | 836 mm | 836 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 165 cm | 175 cm | 180 cm |
| Rider Max Height | 167 cm | 177 cm | 185 cm | 198 cm |
About this model
CARBINE ELITE belongs to the Intense Carbine model. 20 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Intense CARBINE FOUNDATION 12-Speed 2019 is the most economical model, with a starting price of 3299$. Intense CARBINE FACTORY 2019 on the other hand costs 7999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2019 and its price was 6499$. In conclusion, this bike price is 80.58% more expensive than the price of the average Enduro bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
CARBINE ELITE components
Fork
The RockShox Lyrik is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Rock Shox Super Deluxe RC3 rear shock model, which has a travel of 155mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the CARBINE ELITE model has 29″ carbon wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CARBINE ELITE comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 198 cm (4.99 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the CARBINE ELITE. Therefore, climbing or descending will be a breeze.
