Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 200mm -
Travel Rear 208mm -
Fork RockShox BoXXer
-
Groupset X01, GX -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M29 SL 29” Monocoque UD Carbon Front and Rear Triangle 29” DH Frameset
Suspension Fork
Rock Shox Boxxer World Cup 29”, 200mm (Boxxer Red)
Rear Shock
Rock Shox Super Deluxe Coil, 250x70mm, (Spring Rate, Medium 450lb, Large 500lb, XL 550lb)
Drivetrain
Rear Derailleur
SRAM X01 DH, 7 speed
Front Derailleur
N/A
Shift Levers
SRAM GX 7-speed Trigger
Cassette
SRAM XG-795 10-24, 7 speed
Crank
Truvativ Descendant DH 165mm, 36T
Bottom Bracket
BSA (threaded), 83 mm
Chain
PC1110, 11 speed
Chain Guide
E13 LG1+
Pedals
None included
Wheels
Front Hub
DT Swiss 240 32 Hole 20x110 front, 12x157 rear hub 6-bolt, XD
Rear Hub
DT Swiss 240 32 Hole 20x110 front, 12x157 rear hub 6-bolt, XD
Rims
29" DT Swiss FR 1950, 30mm inner width channel
Spokes
DT competition®
Tires
Maxxis Minion DHF 29x2.50 3CG DH Casing Front, Minion DHRII 29x2.40WT 3CG DH Casing Rear
Brakes
Brakes
Shimano XT M8020 4-piston 203mm 6-bolt Rotors
Brake Levers
Shimano XT
Cockpit
Stem
Renthal Integra Direct Mount 31.8mm Clamp. 45mm
Handlebar
Intense Alloy 31.8 mm x 800mm
Grips
Intense Dual Lock-on
Headset
Cane Creek 40 Series, ZS49/ZS56.30
Seat
Saddle
Fabric Radius Elite
Seatpost
Intense Alloy Straight 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 342.7 mm | 342.7 mm | 342.7 mm |
| Stack | 601 mm | 601 mm | 623 mm |
| Reach | 426 mm | 441 mm | 471 mm |
| Top Tube Length | 561.4 mm | 582 mm | 616 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 459 mm | 459 mm | 459 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 90 mm | 90 mm | 115 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1233 mm | 1248 mm | 1289 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm |
| Standover Height | 792 mm | 791 mm | 803 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
M29 ELITE is an Intense M29 model. There are 14 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Intense M29 ELITE 2019 is the cheapest bike model and costs 5999$. Intense M29 FRO 2019 is the most expensive one and costs 10000$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Downhill bikes
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 5999$. In conclusion, this bike price is 76.91% more expensive than the price of the average Downhill bike.
M29 ELITE components
Fork
The fork installed on this bike is the RockShox BoXXer model. The travel on this model is 200mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Rock Shox Super Deluxe Coil rear shock model, which has a travel of 208mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Intense M29 ELITE 2019, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Intense M29 ELITE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
