Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 115mm -
Fork RockShox Pike RCT3
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox Pike RCT3 Solo Air, Boost
Rear Shock
RockShox Monarch RT3, 200mm x 51mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, trigger, 12-speed
Cassette
SRAM XG-1295 X01 Eagle, 10-50 tooth, 12-speed
Crank
SRAM Stylo Carbon Eagle, Boost, 175mm length
Bottom Bracket
SRAM GXP BB92, press fit
Chain
SRAM GX Eagle, 12-speed
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
DT Swiss 350 Classic, Front: Boost, 15mm x 110mm, 6-bolt, Rear: 12mm x 148mm, XD
Rear Hub
DT Swiss 350 Classic, Front: Boost, 15mm x 110mm, 6-bolt, Rear: 12mm x 148mm, XD
Rims
Intense Recon Trail Pacific Rim, carbon, 28 hole, 26mm depth, 30mm inner channel
Spokes
DT Swiss
Tires
Maxxis Forekaster F120, 2.35" DC EXO TR
Brakes
Brakes
SRAM Guide RS with 180mm front/160mm rear rotors
Brake Levers
SRAM Guide RS
Cockpit
Stem
Intense Recon Elite, 50mm length
Handlebar
Intense, carbon, 760mm width
Grips
Intense Dual Lock-on
Headset
Cane Creek 40 Series, ZS44/EC49.40
Seat
Saddle
Fabric Scoop Radius Elite, chromoly rails
Seatpost
FOX Transfer, 150mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.33 mm | 1.29 mm | 1.23 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Stack | 571 mm | 583 mm | 594 mm | 594 mm |
| Reach | 414 mm | 437 mm | 459 mm | 484 mm |
| Top Tube Length | 564 mm | 589 mm | 614 mm | 640 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 375 mm | 445 mm | 483 mm | 514 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 102 mm | 115 mm | 127 mm | 127 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 1117 mm | 1144 mm | 1170 mm | 1195 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 773 mm | 782 mm | 789 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Spider Elite belongs to the Intense Spider model. There are 10 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
The most economical model, the Intense Spider Alloy Foundation 2018 has a starting price of 2399$. Intense Spider Factory 2018 on the other hand is the most expensive at 7999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Intense released this model in 2018, its price was 5999$. If we compare this with the average Crosscountry bike cost we notice that the price is 214.91% higher.
Overview of components
Fork
The RockShox Pike RCT3 is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the RockShox Monarch RT3 rear shock model, which has a travel of 115mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Spider Elite are the 27.5″ carbon type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Spider Elite comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Spider Elite. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
