Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 155mm -
Fork Fox Performance Float 38
-
Groupset Deore, e*thirteen -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery BT-E8010, FOR STEPS, 504Wh. Battery lock w/2 keys -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tazer Performance E Monocoque carbon frame. Optimized layup carbon fiber. Alloy top link, internal shift, Dropper Post, Brake, Display unit routing, E*Spec Chainguide mount pattern, Flak guard armor, Integrated mud guard, 155mm Travel.
Suspension Fork
FOX Performance Float 38, 29", 160mm, GRIP Damper, 51mm Offset
Rear Shock
FOX Float X Performance Elite 185x55 2Pos on SM/MD/LG, FOX Float X2 Performance Elite 185x55 2Pos on XL
Drivetrain
Rear Derailleur
Shimano Deore 12SP
Shift Levers
Shimano Deore 12SP
Cassette
Shimano Deore 12SP / 11-51T
Crank
e*Thirteen E*Spec 34 Tooth Chainring 165mm length
Chain
Shimano Deore 12SP
Wheels
Front Hub
INTENSE E-MTN
Rear Hub
INTENSE E-MTN
Rims
e*Thirteen E*Spec Plus 30mm 29" (front), e*Thirteen E* spec Plus 35mm 27.5" (rear)
Tires
MAXXIS Minion DHR II MAXX Terra 3C Exo + - 29" x 2.60" Front . 27.5" x 2.80" Rear
Brakes
Brakes
Shimano XT-M6120 w/ 203mm RT-76 Zee Rotors
Cockpit
Stem
e*Thirteen Base 35 40mm
Handlebar
e*Thirteen Base 35 800mm
Grips
INTENSE Lock-On
Seat
Saddle
SDG BEL-AIR
Seatpost
e*Thirteen Infinite Dropper w/ adjustable travel, I-SPEC EV, 31.6mm, 180mm
Motor & Battery
Motor
Shimano Steps E7000 25KM/H 250W 60Nm Torque
Battery
BT-E8010, FOR STEPS, 504Wh. Battery lock w/2 keys
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.38 mm | 1.3 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm | 351 mm |
| Front Center | 754 mm | 785 mm | 815 mm | 843 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 611 mm | 626 mm | 634 mm | 634 mm |
| Reach | 408 mm | 432 mm | 459 mm | 489 mm |
| Top Tube Length | 573 mm | 604 mm | 629 mm | 662 mm |
| Seat Tube Angle | 74.9 ° | 74.9 ° | 74.9 ° | 74.9 ° |
| Seat Tube Length | 394 mm | 419 mm | 445 mm | 470 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 114 mm | 124 mm | 124 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1198 mm | 1228 mm | 1259 mm | 1288 mm |
| Bottom Bracket Drop | 8 mm | 9 mm | 9 mm | 9 mm |
| Standover Height | 802 mm | 807 mm | 817 mm | 830 mm |
| Front Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Rear Travel | 155 mm | 155 mm | 155 mm | 155 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
TAZER FOX completes the Intense E Tazer model. 19 e-bikes variations carry this model name so far. You can easily view all of the Intense E Tazer e-bikes models from 2022, here.
Model range prices
Intense TAZER DVO 2022 is the most economical model, with a starting price of 6999$. Intense TAZER FOX Pro 2022 on the other hand costs 7999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 7999$. Comparing this to the average Enduro e-bike price, we see that the price is 67.17% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The Fox Performance Float 38 is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The TAZER FOX has a rear shock with a travel of 155mm. The model FOX Float X Performance Elite 185×55 is the one installed in this e-bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on TAZER FOX are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Intense TAZER FOX has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the TAZER FOX. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
