Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Travel Front 63mm -
Fork Suntour MOBIE
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 350W 75Nm mid-drive -
Battery Bosch PowerTube Li-Ion 36 V -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Integrale 1.5, aluminium
Suspension Fork
Suntour Mobie45 Air LO, 15 mm QR
Drivetrain
Rear Derailleur
Shimano Deore XT
Shift Levers
Shimano Deore XT
Crank
aluminium
Bottom Bracket
Integrated in Drive Unit
Chain
Shimano SLX M7100, 12-speed
Pedals
Urban Light, with anti slip protection and reflector
Wheels
Rims
Rodi TRYP35, with double eyelets
Brakes
Brakes
Magura MT5 Speed, hydraulic disc brake
Disk Rotors
180
Cockpit
Stem
Concept EX, adjustable
Handlebar
Concept EX Riser
Seat
Saddle
Ergon SM10
Seatpost
Concept EX, aluminium
Motor & Battery
Motor
Bosch Performance Line Speed, 36 V / 350 W / 75 Nm (4.Generation)
Battery
Bosch PowerTube Li-Ion 36 V
Remote
Bosch Kiox colour display with walk assist
Charger
Bosch, 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.533 mm | 1.533 mm | 1.535 mm | 1.534 mm |
| Front Center | 652 mm | 661 mm | 670 mm | 680 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 66 mm | 66 mm | 66 mm |
| Stack | 621 mm | 630 mm | 640 mm | 649 mm |
| Reach | 405 mm | 411 mm | 417 mm | 423 mm |
| Top Tube Length | 595 mm | 604 mm | 613 mm | 622 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm | 485 mm |
| Wheelbase | 1133 mm | 1142 mm | 1151 mm | 1161 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ENDEAVOUR 7.B EXCITE 45 completes the Kalkhoff E Endeavour model. There are 46 e-bikes that carry this model name. You can easily view all of the Kalkhoff E Endeavour e-bikes models from 2020, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The ENDEAVOUR 7.B EXCITE 45 comes factory-installed with the Suntour MOBIE fork. This has a travel range of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Kalkhoff ENDEAVOUR 7.B EXCITE 45 2020, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ENDEAVOUR 7.B EXCITE 45 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
