Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Endurance Concept - Aluminium alloy, tapered HT, internal routing
Suspension Fork
KELLYS Carbon - 1.5 tapered steerer
Drivetrain
Rear Derailleur
SHIMANO Claris R2000 (direct mount)
Shift Levers
SHIMANO Claris ST-R2000 Dual Control
Cassette
SHIMANO CS-HG50-8 (11-32T)
Crank
SHIMANO Claris R2000 (50x34T) - length 170mm (S - M), 175mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC Z8 (108 links)
Wheels
Front Hub
SHIMANO Claris 2400 (32 holes)
Rear Hub
SHIMANO Claris 2400 (32 holes)
Rims
KELLYS Spark 622x15 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Lugano K-Guard 25-622 (700x25C)
Brakes
Brakes
TEKTRO
Brake Levers
SHIMANO Claris ST-R2000 Dual Control
Cockpit
Stem
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
Handlebar
KLS Active Road - diam 31.8mm / width 400m (S), 420mm (M), 440mm (L)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active - diam 30.9mm / length 350mm (S - M), 400mm (L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ARC 10 belongs to the Kellys Arc model. There are 9 bikes that carry this model name. Take a sneak peek at all Kellys Arc bikes models from 2021, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
According to our math, the average price for a trustworthy Race bike is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ARC 10 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on ARC 10 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Kellys ARC 10 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Kellys ARC 10 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
