Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Endurance Concept - Aluminium alloy, tapered HT, internal routing
Suspension Fork
KELLYS Carbon - 1.5 tapered steerer
Drivetrain
Rear Derailleur
SHIMANO Claris R2000 (direct mount)
Shift Levers
SHIMANO Claris ST-R2000 Dual Control
Cassette
SHIMANO CS-HG50-8 (11-32T)
Crank
SHIMANO Claris R2000 (50x34T) - length 170mm (S - M), 175mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC Z8 (108 links)
Wheels
Front Hub
SHIMANO Claris 2400 (32 holes)
Rear Hub
SHIMANO Claris 2400 (32 holes)
Rims
KELLYS Spark 622x15 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Lugano K-Guard 25-622 (700x25C)
Brakes
Brakes
TEKTRO
Brake Levers
SHIMANO Claris ST-R2000 Dual Control
Cockpit
Stem
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
Handlebar
KLS Active Road - diam 31.8mm / width 400m (S), 420mm (M), 440mm (L)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active - diam 30.9mm / length 350mm (S - M), 400mm (L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ARC 10 completes the Kellys Arc model. There are 9 bikes that carry this model name. Take a sneak peek at all Kellys Arc bikes models from 2022, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
ARC 10 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Kellys ARC 10 2022, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The ARC 10 has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
ARC 10 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
