Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Endurance Concept - Aluminium alloy, tapered HT, internal routing
Suspension Fork
KELLYS Carbon - 1.5 tapered steerer
Drivetrain
Rear Derailleur
SHIMANO Sora R3000 (direct mount)
Front Derailleur
SHIMANO Sora R3000 (brazed-on mount)
Shift Levers
SHIMANO Sora ST-R3000 Dual Control
Cassette
SHIMANO CS-HG300-9 (11-32T)
Crank
SHIMANO Sora R3000 (50x34T) - length 170 mm (S), 175 mm (M - L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC X9 (108 links)
Wheels
Front Hub
SHIMANO Claris 2400 (32 holes)
Rear Hub
SHIMANO Claris 2400 (32 holes)
Rims
KELLYS Spark 622x15 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Lugano 25-622 (700x25C) K-Guard, Silica
Brakes
Brakes
TEKTRO
Brake Levers
SHIMANO Sora ST-R3000 Dual Control
Cockpit
Stem
KLS Active Road - diam 28.6 mm / bar bore 31.8 mm / 6° / length 90 mm (S), 100 mm (M), 110 mm (L)
Handlebar
KLS Active Road - diam 31.8 mm / width 400m (S), 420 mm (M), 440 mm (L)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ARC 30 completes the Kellys Arc model. 9 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Kellys ARC 10 2023 is the cheapest bike model and costs 1114$. Kellys ARC 50 2023 is the most expensive one and costs 1592$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 1273$. Comparing the average cost of a Race bike to this one, you will see that ARC 30 price is 163.16% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
ARC 30 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Kellys ARC 30 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The ARC 30 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
