Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Endurance Concept - Aluminium alloy Disc, flat mount, tapered HT, internal routing
Suspension Fork
KELLYS Carbon Disc - 1.5 tapered steerer, post mount disc brake
Drivetrain
Rear Derailleur
SHIMANO 105 R7000 (direct mount)
Shift Levers
SHIMANO 105 ST-R7000 Dual Control
Cassette
SHIMANO CS-R7000-11 (11-32T)
Crank
SHIMANO RS510 compact (50x34T) - length 172.5mm (S - M), 175mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC X11 EL (108 links)
Wheels
Front Hub
NOVATEC Disc (28 holes)
Rear Hub
NOVATEC Disc (28 holes)
Rims
KELLYS Spark 622x15 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Lugano K-Guard 25-622 (700x25C)
Brakes
Brakes
TEKTRO Spyre Mechanical Disc
Brake Levers
SHIMANO 105 ST-R7000 Dual Control
Disk Rotors
160mm front / 160mm rear
Cockpit
Stem
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
Handlebar
KLS Active Road - diam 31.8mm / width 400m (S), 420mm (M), 440mm (L)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active - diam 30.9mm / length 350mm (S - M), 400mm (L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
ARC 50 completes the Kellys Arc model. Kellys released 9 bikes variations of this model so far. Take a sneak peek at all Kellys Arc bikes models from 2021, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ARC 50 components
Fork material
ARC 50 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Kellys ARC 50 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kellys ARC 50 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
