Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR M3010, 50mm, coil spring (threaded steerer)
Drivetrain
Rear Derailleur
SHIMANO TY300 (direct mount)
Shift Levers
SHIMANO ST-EF41-7 EZ-fire Plus
Cassette
SHIMANO CS-HG200-7 (12-32T)
Crank
SHIMANO TY301 (48x38x28T) - length 170mm (S), 175mm (M - L)
Bottom Bracket
cartridge (120mm)
Chain
KMC Z7 (114 links)
Pedals
plastic
Wheels
Front Hub
alloy / SHIMANO TY500-7 (32 holes)
Rear Hub
alloy / SHIMANO TY500-7 (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 42-622 (700x42C)
Brakes
Brakes
APSE V-brake
Brake Levers
APSE
Cockpit
Stem
KALLOY adjustable - diam 25.4mm / bar bore 25.4mm / length 90mm (S), 100mm (M - L)
Handlebar
steel RiseBar - diam 25.4mm / rise 35mm / width 630mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
KLS CrossLine
Seatpost
KALLOY suspension - diam 30.9mm / length 300mm (S), 350mm (M - L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
CARSON 10 is a Kellys Carson model. Kellys released 18 bikes variations of this model so far. Take a sneak peek at all Kellys Carson bikes models from 2021, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter bikes
Our math shows that the average cost of a dependable Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 50mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Kellys CARSON 10 2021, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kellys CARSON 10 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
