Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 50mm -
Fork Suntour
-
Groupset Altus, Shimano -
Suspension Hardtail -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR M3010, 50mm, coil spring (threaded steerer)
Drivetrain
Rear Derailleur
SHIMANO Altus M310 (direct mount)
Shift Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cassette
SHIMANO CS-HG200-8 (12-32T)
Crank
SHIMANO TY301 (48x38x28T) - length 175mm
Bottom Bracket
cartridge (120mm)
Chain
KMC Z8 (114 links)
Pedals
plastic
Wheels
Front Hub
alloy (32 holes)
Rear Hub
alloy (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 42-622 (700x42C)
Brakes
Brakes
APSE V-brake
Brake Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cockpit
Stem
KALLOY adjustable - diam 25.4mm / bar bore 25.4mm / length 100mm
Handlebar
steel RiseBar - diam 25.4mm / rise 35mm / width 630mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
KLS CrossLine
Seatpost
KALLOY suspension - diam 30.9mm / length 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 700 | 700 |
Model Overview
CARSON 30 is part of the Kellys Carson model. 18 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
CARSON 30 components
Fork
The fork installed on this bike is the Suntour model. The travel on this model is 50mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the CARSON 30 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Kellys CARSON 30 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
