Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX-E25 NLO, 63 mm, coil spring
Drivetrain
Rear Derailleur
SHIMANO Deore XT T8000 (direct mount)
Front Derailleur
SHIMANO Deore T6000 (34.9 mm)
Shift Levers
SHIMANO Deore SL-M6000 Rapidfire Plus
Cassette
SHIMANO CS-HG50-10 (11-36T)
Crank
SHIMANO T521 Hollowtech Octalink (48x36x26T) - length 175 mm
Bottom Bracket
SHIMANO BB-ES300 Octalink
Chain
KMC X10 EL (114 links)
Pedals
alloy
Wheels
Front Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rear Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes / eyelets)
Spokes
steel
Tires
MICHELIN Protek BR 42-622 (700x40C) ReflectiveLine
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
PROMAX a-head adjustable - diam 28.6 mm / bar bore 31.8 mm / length 105 mm
Handlebar
alloy RiseBar - diam 31.8 mm / width 640 mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Lookin Visual Royalgel
Seatpost
KALLOY suspension - diam 30.9 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
CARSON 90 belongs to the Kellys Carson model. There are 18 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Kellys CARSON 10 2023 is the most economical model, with a starting price of 700$. Kellys CARSON 90 2023 on the other hand costs 1379$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter bikes average price
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Kellys released this model in 2023, its price was 1379$. Comparing the average cost of a Commuter bike to this one, you will see that CARSON 90 price is 80.97% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
CARSON 90 components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The CARSON 90 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kellys CARSON 90 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
