Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery SHIMANO BT-E8010, 504Wh / capacity 14Ah -
Drivetrain Internally Geared Hub -
Brakes Coaster
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS e-FRAME City Aluminium alloy monotube, semi-integrated battery, tapered HT, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX-E25 NLO, 63mm, coil spring
Drivetrain
Shift Levers
SHIMANO Nexus SL-C6000-8 Revoshift
Cassette
for internal hub 18T
Crank
SHIMANO E5000 (38T) - length 170mm
Chain
KMC Z1 (102 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO TX505 / SHIMANO Nexus C6001-8 Disc Center Lock / coaster brake (32 holes)
Rear Hub
SHIMANO TX505 / SHIMANO Nexus C6001-8 Disc Center Lock / coaster brake (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes)
Spokes
stainless steel black
Tires
IMPAC Streetpac 47-622 (28x1.75) ReflectiveLine
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
PROMAX a-head adjustable - diam 28.6mm / bar bore 31.8mm / length 85mm (S), 105mm (M)
Handlebar
KALLOY RiseBar - diam 31.8mm / width 640mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Freedom Royalgel
Seatpost
KALLOY suspension - diam 30.9mm / length 300mm (S), 350mm (M)
Motor & Battery
Motor
SHIMANO STEPS E5000, 36V
Battery
SHIMANO BT-E8010, 504Wh / capacity 14Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Wheels | 700 | 700 |
Model Overview
ESTIMA 40 504Wh completes the Kellys E Estima model. Kellys launched 8 e-bikes of this model so far. Take a sneak peek at all Kellys E Estima e-bikes models from 2022, by clicking here.
Model range prices
Kellys ESTIMA 10 SH 504Wh 2022 is the cheapest e-bike model and costs 2760$. Kellys ESTIMA 40 SH 504Wh 2022 is the most expensive one and costs 2972$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for General Urban e-bikes
According to our math, the average price for a trustworthy General Urban e-bike is 2098$. However, even though the average price of a General Urban e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
ESTIMA 40 504Wh components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the ESTIMA 40 504Wh model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kellys ESTIMA 40 504Wh has Coaster brakes installed. These brakes are pretty efficient, and they’re not so pricey. However, if your chain falls off or snaps, your coaster brakes won’t function anymore.
