Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 75mm -
Fork Suntour NEX
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX-E25 NLO, 75mm, coil / Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO Alivio M4000 (direct mount)
Shift Levers
SHIMANO Alivio SL-M4000 Rapidfire Plus
Cassette
SHIMANO CS-HG300-9 (11-34T)
Crank
SHIMANO Acera T3010 (48x36x26T) - length 175mm
Bottom Bracket
cartridge (124.5mm)
Chain
KMC X9 (114 links)
Pedals
alloy
Wheels
Front Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rear Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes / eyelets)
Spokes
stainless steel black
Tires
MICHELIN Protek Cross 42-622 (700x40C) ReflectiveLine
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Disk Rotors
160mm front / 160mm rear
Cockpit
Stem
KLS CRX 70 adjustable - diam 28.6mm / bar bore 31.8mm / length 95mm
Handlebar
KLS CRX 70 RiseBar - diam 31.8mm / rise 25mm / width 640mm (M), 660mm (L)
Grips
KLS Token 2Density
Seat
Saddle
SELLE ROYAL Vivo
Seatpost
KLS Active - diam 27.2mm / length 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 700 | 700 |
About this model
PHANATIC 40 belongs to the Kellys Phanatic model. Kellys launched 19 bikes of this model so far. Take a sneak peek at all Kellys Phanatic bikes models from 2022, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
PHANATIC 40 components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the PHANATIC 40 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
