Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravel Concept - Aluminium alloy Disc, flat mount, tapered HT, internal routing, 12x142mm thru axle
Suspension Fork
KELLYS Carbon Disc - 1.5 tapered steerer, flat mount disc brake, 12x100mm thru axle
Drivetrain
Rear Derailleur
SHIMANO GRX RX812 (direct mount)
Shift Levers
SHIMANO GRX BL-RX600 / ST-RX600 Dual Control
Cassette
SunRace CSMS7 (11-42T)
Crank
SHIMANO GRX RX600-1 (40T) - length 172.5mm (S - M), 175mm (L - XL)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC X11 EL (112 links)
Wheels
Front Hub
NOVATEC Disc (32 holes)
Rear Hub
NOVATEC Disc (32 holes)
Rims
DT SWISS G 540 Disc 700Cx24 (32 holes)
Spokes
stainless steel black
Tires
SCHWALBE G-One Allround 40-622 (700x38C) RaceGuard, folding
Brakes
Brakes
SHIMANO GRX RX400 Hydraulic Disc
Brake Levers
SHIMANO GRX BL-RX600 / ST-RX600 Dual Control
Disk Rotors
160mm front / 160mm rear
Cockpit
Stem
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L), 120mm (XL)
Handlebar
GravelBar - diam 31.8mm / width 400mm (S), 420mm (M), 440mm (L), 460mm (XL)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active Road - diam 30.9mm / length 350mm (S), 400mm (M - XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SOOT 70 completes the Kellys Soot model. Kellys launched 16 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Gravel bikes average weight
Gravel bikes have an average weight of 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Kellys SOOT 70 it’s weighing 10.7 kg (23.59 lbs). At this weight, is much heavier than average. In other words, this model is 31.61% heavier than the average Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
SOOT 70 components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Kellys SOOT 70 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kellys SOOT 70 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
