Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravel Concept - Carbon Disc, flat mount, tapered HT, internal routing, 12x142mm thru axle
Suspension Fork
KELLYS Carbon Disc - 1.5 tapered steerer, flat mount disc brake, 12x100mm thru axle
Drivetrain
Rear Derailleur
SHIMANO GRX RX400 (direct mount)
Shift Levers
SHIMANO GRX ST-RX400 Dual Control
Cassette
SHIMANO CS-HG500-10 (11-34T)
Crank
SHIMANO GRX RX600-10 (46x30T) - length 172.5mm (S - M), 175mm (L)
Bottom Bracket
SHIMANO Press-Fit BB-RS500-PB
Chain
KMC X10 EL (112 links)
Wheels
Front Hub
NOVATEC Disc (32 holes)
Rear Hub
NOVATEC Disc (32 holes)
Rims
KELLYS Grind Disc 622x17 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Smart Sam Performance 42-622 (700x40C) ADDIX
Brakes
Brakes
SHIMANO GRX RX400 Hydraulic Disc
Brake Levers
SHIMANO GRX ST-RX400 Dual Control
Cockpit
Stem
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
Handlebar
GravelBar - diam 31.8mm / width 400mm (S), 420mm (M), 440mm (L)
Grips
KLS bar tape
Seat
Saddle
KLS SlipStream cr-mo rails
Seatpost
KLS Active Road - diam 27.2mm / length 350mm (S), 400mm (M - L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
SOOT 80 completes the Kellys Soot model. Kellys launched 16 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 2441$. In conclusion, this bike price is 0.86% lower than the price of the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the SOOT 80 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SOOT 80 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
SOOT 80 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
