Kellys THEOS F90 29″/27.5″ 725Wh 2022

2022 E-bike
E-bike
Open compare Use advisor
Kellys Theos F90 2927.5 725wh 2022

Bike details

Overview

Key information split into simple groups.

Bike summary

  • Category
  • Frame Carbon
  • Wheels 29"
  • Travel Front 180mm
  • Travel Rear 170mm
  • Fork Fox Factory Float 38
  • Groupset XT Di2
  • Suspension Full
  • Motor Shimano 250W 85Nm mid-drive
  • Battery KELLYS Re-Charge K1 Li-ion internal removable 725Wh / capacity 20Ah, co-developed by Kellys-BMZ
  • Drivetrain 1 × 11 Electronic
  • Brakes Hydraulic Disc

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Frame

KELLYS THEOS F series - Thermoplastic Hybrid Steel-Carbon Composite a.k.a. FEATHER® by Rein4ced assembled by advanced robotic manufacturing / Think Link suspension system, 170mm rear travel, integrated removable battery, 1.8“ tapered HT, post mount 203mm, mullet 29 / 27.5+ wheelset, 12x148mm Boost thru axle / Made in EU

Suspension Fork

FOX 38 Float Factory, Kashima Coat (29) Boost, 180mm, Float Evol / GRIP2 damper / 15QR thru axle

Rear Shock

ROCK SHOX Super Deluxe Ultimate, DebonAir / RCT / Open-Threshold (230x65mm)

Drivetrain

Rear Derailleur

SHIMANO Deore XT Di2 M8050 (direct mount)

Shift Levers

SHIMANO Deore XT Di2 SW-M8050-R Firebolt

Cassette

SHIMANO CS-M7000-11 (11-46T)

Crank

SHIMANO Deore XT M8150 (34T) - length 170mm

Bottom Bracket

BSA, 73mm, threaded

Chain

KMC e11T (116 links)

Pedals

plastic

Wheels

Rims

DT SWISS H 1700 29 622x30 Center Lock front / DT SWISS H 1700 Spline 27.5 584x35 Center Lock rear (15x110mm / 12x148mm)

Tires

SCHWALBE Eddy Current Evo SuperTrail 65-622 (29x2.60) Tubeless Easy, ADDIX Soft, folding front / SCHWALBE Eddy Current Evo SuperGravity 70-584 (27.5x2.80) Tubeless Easy, ADDIX Soft, folding rear

Brakes

Brakes

SHIMANO Deore XT M8120 Hydraulic Disc

Brake Levers

SHIMANO Deore XT BL-M8100 Hydraulic Disc

Disk Rotors

SHIMANO MT800 203mm front / SHIMANO EM810 203mm rear

Cockpit

Stem

RACE FACE Aeffect R 35 - diam 28.6mm / bar bore 35mm / 0° / length 50mm

Handlebar

RACE FACE Aeffect R 35 RiseBar - diam 35mm / rise 20mm / width 780mm

Grips

KLS Poison

Seat

Saddle

fi´zi:k Taiga S-alloy rails

Seatpost

FOX Transfer Factory Remote Telescopic, Kashima Coat - diam 30.9mm / travel 150mm (M), 175mm (L)

Motor & Battery

Motor

SHIMANO EP8 (021) 85Nm, 36V

Battery

KELLYS Re-Charge K1 Li-ion internal removable 725Wh / capacity 20Ah, co-developed by Kellys-BMZ

Fit data

Geometry

Numbers for sizing and ride feel.

SizeMDLG
Wheels29"29"

About this model

THEOS F90 29″/27.5″ 725Wh belongs to the Kellys E Theos model. 24 e-bikes variations carry this model name so far. Take a sneak peek at all Kellys E Theos e-bikes models from 2022, by clicking here.

Model range prices

Kellys THEOS i50 SH 29″/27.5″ 630Wh 2022 is the most affordable e-bike of this model and has a price of 4777$. On the other hand, Kellys THEOS F90 SH 29″/27.5″ 725Wh 2022, is the most expensive and costs 10086$.

Safety

Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.

Average price for Enduro e-bikes

According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.

THEOS F90 29″/27.5″ 725Wh components

Fork

The Fox Factory Float 38 is included from the factory. It has a travel distance of 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.

Rear Shock

The THEOS F90 29″/27.5″ 725Wh has a rear shock with a travel of 170mm. The model ROCK SHOX Super Deluxe Ultimate is the one installed in this e-bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.

Wheels size

The wheels on THEOS F90 29″/27.5″ 725Wh are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.

Brakes

When you want to stop the bike in time, the brakes are vital. The THEOS F90 29″/27.5″ 725Wh has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.

Dropper post

The Kellys model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
