Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 20mm -
Travel Rear 210mm -
Fork Fox Performance Elite Float 40
-
Groupset Zee -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KHS 650B F.A.S.T. DH Frame w/ 8.3” travel, 1.5HT, 83mm BB, ISCG05 mount
Suspension Fork
Fox 40 Float Performance Elite, 27.5, Fit 4, Evol, Low Speed Compression, Rebound Adj, 20mm
Rear Shock
Fox Float X2 Air, External Rebound & Compression adjust
Drivetrain
Rear Derailleur
Shimano Zee
Front Derailleur
N/A
Shift Levers
Shimano Zee, Right only
Cassette
Shimano CS-5700, 11-25T, 10-speed
Crank
Shimano Zee, 38T, w/MRP G3 Chain Guide System, S-L: 165, XL: 170
Bottom Bracket
Shimano Zee
Chain
Shimano CN-HG95, 10-Speed
Chain Guide
MRP G3
Pedals
N/A
Wheels
Front Hub
Formula Disc, 20mm thru-axle front, 150x12mm rear
Rear Hub
Formula Disc, 20mm thru-axle front, 150x12mm rear
Rims
WTB STP-I25 TCS, Disc, Double Wall, 27.5x32H, Tubeless Ready
Spokes
14G Black, 32x32
Tires
Maxxis Minion DHF, 650B x 2.5 Front, DHR, 2.4 Rear, DH Casing
Brakes
Brakes
Shimano Zee, F: 203mm Rotors w/metal fin brake pads
Brake Levers
Shimano Zee
Cockpit
Stem
Kore Torsion Direct Mount, 50mm
Handlebar
Kore OCD, 35x800mm, 31.8mm
Grips
Q2 lock-on
Headset
FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Seat
Saddle
WTB High Tail/KHS Team Graphics
Seatpost
Kind Shock Ether, 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.5 mm | 1.41 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm |
| Stack | 600 mm | 600 mm | 600 mm |
| Reach | 375 mm | 400 mm | 425 mm |
| Top Tube Length | 548 mm | 573 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 393 mm | 405 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm |
| Standover Height | 752 mm | 744 mm | 740 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
DH 650 PRO completes the Khs Dh model. KHS launched 11 bikes of this model so far. You can easily view all of the Khs Dh bikes models from 2018, here.
Model range prices
The most economical model, the KHS DH 650 PRO 2018 has a starting price of 5299$. KHS DH 650 TEAM 2018 on the other hand is the most expensive at 6699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5299$. If we compare this with the average Enduro bike cost we notice that the price is 47.24% more expensive.
Overview of components
Fork
The DH 650 PRO comes factory-installed with the Fox Performance Elite Float 40 fork. This has a travel range of 20mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
KHS DH 650 PRO bike has the Fox Float X2 Air model installed, and has a travel of 210mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on DH 650 PRO are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DH 650 PRO comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
KHS DH 650 PRO comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
