Knolly Endorphin 6.0 Deore 27.5 2023
2023 Mountain
Estimate price |
4,199$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 150mm -
Fork Marzocchi Bomber Z1
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Neutral
150cm - 163cm
XS Slack
150cm - 163cm
SM Neutral
161cm - 173cm
SM Slack
161cm - 173cm
MD Neutral
171cm - 183cm
MD Slack
171cm - 183cm
LG Neutral
181cm - 188cm
LG Slack
181cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6066 Aluminum, Custom Titanium Hardware
Suspension Fork
Marzocchi Z1 27.5” 160mm, 44mm Offset
Rear Shock
Marzocchi Bomber Air 185x55
Drivetrain
Shift Levers
Shimano Deore 12spd M6100 (I-Spec EV)
Cassette
Shimano Deore M6100 12spd, 10-51T, Hyperglide+
Crank
Shimano Deore M6130 30T, 170mm
Bottom Bracket
Shimano MT501 BSA
Chain
Shimano Deore M6100
Wheels
Rims
DT Swiss M1900 SPLINE 28h Straight-Pull (MS)
Tires
Front: Maxxis Assegai 27.5" 2.5WT 3C MaxxGrip EXO+, Rear: Maxxis DHR2 27.5" 2.4" 3C MaxxTerra EXO+
Brakes
Brakes
Shimano Deore 4 Piston M6120
Cockpit
Stem
RaceFace Aeffect R 35mm x 40mm
Handlebar
RaceFace Aeffect R 35x780mm, 20mm Rise
Grips
Spank Spoon
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Neutral | XS Slack | SM Neutral | SM Slack | MD Neutral | MD Slack | LG Neutral | LG Slack |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.39 mm | 1.39 mm | 1.33 mm | 1.33 mm | 1.28 mm | 1.28 mm |
| Bottom Bracket Height | 343.5 mm | 333.5 mm | 343.5 mm | 333.5 mm | 343.5 mm | 333.5 mm | 343.5 mm | 333.5 mm |
| Front Center | 745 mm | 745 mm | 774 mm | 774 mm | 804 mm | 804 mm | 832 mm | 832 mm |
| Rake | 42 mm | 36 mm | 42 mm | 36 mm | 42 mm | 36 mm | 41 mm | 35 mm |
| Trail | 123 mm | 133 mm | 123 mm | 133 mm | 123 mm | 133 mm | 124 mm | 134 mm |
| Stack | 604 mm | 604 mm | 614 mm | 614 mm | 623 mm | 623 mm | 632 mm | 632 mm |
| Reach | 418 mm | 418 mm | 443 mm | 443 mm | 468 mm | 468 mm | 493 mm | 493 mm |
| Top Tube Length | 565 mm | 565 mm | 592 mm | 592 mm | 619 mm | 619 mm | 646 mm | 646 mm |
| Seat Tube Angle | 76 ° | 75.5 ° | 76 ° | 75.5 ° | 76 ° | 75.5 ° | 76 ° | 75.5 ° |
| Seat Tube Length | 335 mm | 335 mm | 350 mm | 350 mm | 390 mm | 390 mm | 440 mm | 440 mm |
| Head Tube Angle | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° | 64.5 ° | 64 ° |
| Head Tube Length | 115 mm | 115 mm | 125 mm | 125 mm | 135 mm | 135 mm | 145 mm | 145 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 435 mm | 435 mm | 439 mm | 439 mm |
| Wheelbase | 1176 mm | 1176 mm | 1205 mm | 1205 mm | 1239 mm | 1239 mm | 1271 mm | 1271 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Standover Height | 694 mm | 694 mm | 704 mm | 704 mm | 719 mm | 719 mm | 731 mm | 731 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 150 cm | 150 cm | 161 cm | 161 cm | 171 cm | 171 cm | 181 cm | 181 cm |
| Rider Max Height | 163 cm | 163 cm | 173 cm | 173 cm | 183 cm | 183 cm | 188 cm | 188 cm |
Model Overview
Endorphin 6.0 Deore 27.5 completes the Knolly Endorphin model. There are 9 bikes that carry this model name. Take a sneak peek at all Knolly Endorphin bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Knolly Endorphin 6.1 Deore 27.5 2023 has a starting price of 4199$. Knolly Endorphin 6.0 XT MX29 2023 on the other hand is the most expensive at 5499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4199$. If we compare this with the average Enduro bike cost we notice that the price is 16.67% higher.
Endorphin 6.0 Deore 27.5 components
Fork
The Endorphin 6.0 Deore 27.5 comes factory-installed with the Marzocchi Bomber Z1 fork. This has a travel range of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Endorphin 6.0 Deore 27.5 has a rear shock with a travel of 150mm. The model Marzocchi Bomber Air 185×55 is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Endorphin 6.0 Deore 27.5 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Knolly Endorphin 6.0 Deore 27.5 bike has 8 sizes, in the range of 150 cm – 188 cm (4.92 ft – 6.17 ft). In short, you can easily find one that suits you.
Dropper post
The Knolly model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
