Knolly Fugitive 138 Deore 2023
2023 Mountain
Estimate price |
3,099$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 138mm -
Fork Marzocchi Bomber Z1
-
Groupset Deore, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM Slack
155cm - 171cm
SM Neutral
155cm - 171cm
MD Slack
169cm - 179cm
MD Neutral
169cm - 179cm
LG Slack
177cm - 189cm
LG Neutral
177cm - 189cm
XL Slack
187cm - 195cm
XL Neutral
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6066 Aluminum, Custom Titanium Hardware
Suspension Fork
Marzocchi Z1 29” 150mm 44mm Offset
Rear Shock
RockShox Super Deluxe Ultimate RCT '22 185x55, CL RM
Drivetrain
Rear Derailleur
Shimano Deore M6100 12spd, Shadow Plus
Shift Levers
Shimano Deore 12spd M6100 (I-Spec EV)
Cassette
Shimano Deore M6100 12spd, 10-51T, Hyperglide+
Crank
Shimano SLX M7120 30T, 170mm
Bottom Bracket
Shimano XT MT800 BSA
Chain
Shimano Deore M6100
Wheels
Rims
DT Swiss M1900 SPLINE 28h Straight-Pull (MS)
Tires
Front: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO, Rear: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO
Brakes
Brakes
Shimano Deore 4 Piston M6120
Cockpit
Stem
RaceFace Aeffect R 35mm x 40mm
Handlebar
RaceFace Aeffect R 35x780mm, 20mm Rise
Grips
Spank / SDG
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Slack | SM Neutral | MD Slack | MD Neutral | LG Slack | LG Neutral | XL Slack | XL Neutral |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.44 mm | 1.36 mm | 1.36 mm | 1.31 mm | 1.31 mm | 1.27 mm | 1.27 mm |
| Bottom Bracket Height | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm |
| Stack | 637 mm | 637 mm | 637 mm | 637 mm | 643 mm | 643 mm | 653 mm | 653 mm |
| Reach | 441 mm | 441 mm | 468 mm | 468 mm | 491 mm | 491 mm | 514 mm | 514 mm |
| Top Tube Length | 580 mm | 580 mm | 614 mm | 614 mm | 647 mm | 647 mm | 678 mm | 678 mm |
| Seat Tube Angle | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° |
| Seat Tube Length | 355 mm | 355 mm | 400 mm | 400 mm | 456 mm | 456 mm | 500 mm | 500 mm |
| Head Tube Angle | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° |
| Head Tube Length | 108 mm | 108 mm | 108 mm | 108 mm | 115 mm | 115 mm | 125 mm | 125 mm |
| Chainstay Length | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm | 438 mm | 436 mm |
| Wheelbase | 1191 mm | 1191 mm | 1218 mm | 1218 mm | 1244 mm | 1244 mm | 1270 mm | 1270 mm |
| Bottom Bracket Drop | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm |
| Standover Height | 696 mm | 696 mm | 724 mm | 724 mm | 775 mm | 775 mm | 788 mm | 788 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 155 cm | 169 cm | 169 cm | 177 cm | 177 cm | 187 cm | 187 cm |
| Rider Max Height | 171 cm | 171 cm | 179 cm | 179 cm | 189 cm | 189 cm | 195 cm | 195 cm |
Model Overview
Fugitive 138 Deore is part of the Knolly Fugitive model. There are 21 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Knolly Fugitive 138 Deore 2023 is the cheapest bike model and costs 3099$. Knolly Fugitive 138 XT 2023 is the most expensive one and costs 6055$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 3099$. Comparing the average cost of a Trail bike to this one, you will see that Fugitive 138 Deore price is 12.2% higher.
Overview of components
Fork
This bike has the Marzocchi Bomber Z1 fork installed. The fork’s travel is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Knolly Fugitive 138 Deore bike has the RockShox Super Deluxe Ultimate RCT ’22 185×55 model installed, and has a travel of 138mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Fugitive 138 Deore are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fugitive 138 Deore comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Knolly Fugitive 138 Deore bike has 8 sizes, in the range of 155 cm – 195 cm (5.09 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Knolly Fugitive 138 Deore includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
