Knolly Tyaughton Steel NX 2023
2023 Mountain
Estimate price |
2,995$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 150mm -
Fork Marzocchi Bomber Z1
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 171cm
MD
169cm - 179cm
LG
177cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Marzocchi Z1 29” 150mm 44mm Offset
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM XG1230 Eagle 11-50T
Crank
SRAM Descendant 170mm 30T Ring
Bottom Bracket
SRAM DUB BSA SB+
Chain
SRAM NX Eagle
Wheels
Rims
Spank Oozy Trail 345 HEX 32h J-Bend (HG) OR RaceFace Aeffect R 30 Trace 28h J-Bend (HG)
Tires
Front: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO, Rear: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO
Brakes
Brakes
SRAM Guide RE
Cockpit
Stem
RaceFace Aeffect R 35mm x 40mm
Handlebar
RaceFace Aeffect R 35x780mm, 20mm Rise
Grips
Spank / SDG
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.36 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 323 mm | 323 mm | 323 mm | 323 mm |
| Stack | 626 mm | 630 mm | 634 mm | 646 mm |
| Reach | 435 mm | 462 mm | 489 mm | 516 mm |
| Top Tube Length | 604 mm | 633 mm | 661 mm | 690 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 404 mm | 456 mm | 506 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 102 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1184 mm | 1215 mm | 1244 mm | 1275 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm | 51 mm |
| Standover Height | 663 mm | 719 mm | 744 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 169 cm | 177 cm | 187 cm |
| Rider Max Height | 171 cm | 179 cm | 189 cm | 195 cm |
About this model
Tyaughton Steel NX belongs to the Knolly Tyaughton model. Knolly released 19 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Knolly Tyaughton Steel Deore 2023 is the most economical model, with a starting price of 1999$. Knolly Tyaughton Titanium XT 2023 on the other hand costs 6195$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 2995$. In conclusion, this bike price is 20.17% smaller than the price of the average Enduro bike.
Tyaughton Steel NX components
Fork
The Marzocchi Bomber Z1 is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Tyaughton Steel NX 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Tyaughton Steel NX has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Tyaughton Steel NX comes in 4 sizes, that range from 155 cm – 195 cm (5.09 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Knolly Tyaughton Steel NX comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
