Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 29" -
Travel Front 150mm -
Fork Marzocchi Bomber Z1
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium
Suspension Fork
Marzocchi Z1 29” 150mm 44mm Offset
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM XG1275 Eagle 10-50T
Crank
SRAM Descendant 170mm 30T Ring
Bottom Bracket
SRAM DUB BSA SB+
Chain
SRAM NX Eagle
Wheels
Rims
Spank Oozy Trail 345 HEX 32h J-Bend OR RaceFace Aeffect R 30 Trace 28h J-Bend
Tires
Front: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO, Rear: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO
Brakes
Brakes
SRAM Guide RE
Cockpit
Stem
RaceFace Aeffect R 35mm x 40mm
Handlebar
RaceFace Aeffect R 35x780mm, 20mm Rise
Grips
Spank / SDG
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.36 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 323 mm | 323 mm | 323 mm | 323 mm |
| Stack | 626 mm | 630 mm | 634 mm | 646 mm |
| Reach | 435 mm | 462 mm | 489 mm | 516 mm |
| Top Tube Length | 604 mm | 633 mm | 661 mm | 690 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 404 mm | 456 mm | 506 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 102 mm | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1184 mm | 1215 mm | 1244 mm | 1275 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm | 51 mm |
| Standover Height | 663 mm | 719 mm | 744 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Tyaughton Titanium NX is part of the Knolly Tyaughton model. Knolly launched 19 bikes of this model so far. You can easily view all of the Knolly Tyaughton bikes models from 2022, here.
Model range prices
The most economical model, the Knolly Tyaughton Steel SLX 2022 has a starting price of 3499$. Knolly Tyaughton Titanium XT 2022 on the other hand is the most expensive at 6999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Tyaughton Titanium NX components
Fork
The Marzocchi Bomber Z1 is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Tyaughton Titanium NX 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tyaughton Titanium NX comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Knolly Tyaughton Titanium NX comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
