Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik Ultimate RC2, 46mm offset
Rear Shock
RockShox Super Deluxe Ultimate RCT
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-50 tooth
Crank
SRAM GX Eagle DUB, 170mm length
Bottom Bracket
SRAM DUB, 73mm English/BSA threaded
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Spank Oozy Trail 345 HEX wheelset, 110x15mm Boost front, 157x12mm SuperBoost rear with XD driver
Rear Hub
Spank Oozy Trail 345 HEX wheelset, 110x15mm Boost front, 157x12mm SuperBoost rear with XD driver
Rims
Spank Oozy Trail 345 HEX wheelset, 32 hole
Spokes
Spank Oozy Trail 345 HEX wheelset, J-bend
Tires
Front: Maxxis Assegai, 3C, EXO+, 27.5" x 2.5", Rear: Maxxis Minion DHR II, 3C, EXO+, 27.5" x 2.4" WT
Brakes
Brakes
SRAM Code R, 4-piston, SRAM CenterLine rotors (200mm front, 180mm rear)
Brake Levers
SRAM Code R
Cockpit
Stem
Spank Split, 40mm length, 35mm bar clamp
Handlebar
Spank Spike Vibrocore, 820mm width, 25mm rise, 35mm clamp diameter
Grips
Spank Spike 33
Headset
Cane Creek 40 Series, ZS44 upper, ZS56 lower
Seat
Saddle
Spank Oozy 280
Seatpost
RockShox Reverb Stealth dropper, 175mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.24 mm | 1.19 mm | 1.17 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Stack | 576 mm | 583 mm | 587 mm | 601 mm |
| Reach | 446 mm | 469.5 mm | 494 mm | 514 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 360 mm | 405 mm | 456 mm | 505 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 103 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1192 mm | 1219 mm | 1245 mm | 1271 mm |
| Bottom Bracket Drop | 9 mm | 9 mm | 9 mm | 9 mm |
| Standover Height | 669 mm | 704 mm | 744 mm | 789 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Warden 160 GX completes the Knolly Warden model. There are 23 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Knolly Warden 168 GX 2022 is the cheapest bike model and costs 5799$. Knolly Warden 168 XT 2022 is the most expensive one and costs 6999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Knolly released this model in 2022, its price was 5799$. Doing a quick comparison, we notice that Warden 160 GX price is 61.13% more expensive than the average cost of an Enduro bike.
Warden 160 GX components
Fork
The fork installed on this bike is the RockShox Lyrik Ultimate model. The travel on this model is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the RockShox Super Deluxe Ultimate RCT rear shock model, which has a travel of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Warden 160 GX bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Warden 160 GX. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
