Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset VIA Centro -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Kona Project Two Aluminum Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Via Centro
Front Derailleur
SRAM Via Centro
Shift Levers
SRAM Via Centro
Cassette
SRAM PG1030 11-36t 10 spd
Crank
48/32t
Bottom Bracket
SRAM Powerspline
Chain
SRAM PC1031
Pedals
VP 198
Wheels
Front Hub
Formula
Rear Hub
Shimano M475
Rims
Freedom by WTB Ryder 21
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Continental CityRide 700x32C
Brakes
Brakes
Avid Elixir 3
Brake Levers
Avid Elixir 3
Disk Rotors
Avid HS1 160mm
Cockpit
Stem
Kona Commuter Deluxe
Handlebar
Kona Deluxe Energy
Grips
Velo Ergo
Headset
TH ZST No.10
Seat
Saddle
Freedom by WTB Aon
Seatpost
Kona Double Clamp w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.55 mm | 1.59 mm | 1.63 mm | 1.65 mm | 1.62 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 284 mm | 284 mm | 287 mm | 287 mm |
| Front Center | 597 mm | 603 mm | 605 mm | 622 mm | 627 mm | 647 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 79 mm | 73 mm | 73 mm | 67 mm | 65 mm |
| Stack | 543 mm | 562 mm | 582 mm | 610 mm | 631 mm | 645 mm |
| Reach | 363 mm | 363 mm | 367 mm | 374 mm | 383 mm | 398 mm |
| Top Tube Length | 518 mm | 528 mm | 543 mm | 558 mm | 578 mm | 598 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 480 mm | 510 mm | 540 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 185 mm | 205 mm | 220 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1020 mm | 1027 mm | 1030 mm | 1046 mm | 1052 mm | 1073 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 66 mm | 66 mm | 63 mm | 63 mm |
| Standover Height | 715 mm | 738 mm | 769 mm | 798 mm | 824 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
DR DEW completes the Kona Dew model. Kona launched 58 bikes of this model so far. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
According to our math, the average price for a trustworthy Commuter bike is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Kona DR DEW 2013, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona DR DEW has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
