Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Groupset Deore, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Aluminum Butted
Suspension Fork
Kona P2 700C
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano FD-M311
Shift Levers
Shimano Acera
Cassette
Shimano HG40 (11-34, 8spd)
Crank
48/38/28
Bottom Bracket
RPM 7420
Chain
Shimano HG40
Pedals
Wellgo LU-A9 / Xerama SP-500
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
Rigida ZAC 2000
Spokes
Sandvik Stainless 15g fr/14g rr
Tires
Continental CountryRide 700x37C
Brakes
Brakes
Shimano 486 Hydraulic Disc 6"
Brake Levers
Shimano 486 Hydraulic Disc
Cockpit
Stem
Kona Road (6°±, 45-49=75, 52-54=90)
Handlebar
Kona XC/BC Riser (31.8mm x 620mm Wide)
Grips
Kona Lisa
Headset
TH
Seat
Saddle
Kona Comfort
Seatpost
Kona Road
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 49cm | 52cm | 54cm |
|---|---|---|---|---|
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 277 mm |
| Front Center | 578 mm | 592 mm | 601 mm | 595 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 512 mm | 525 mm | 537 mm | 549 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 470 mm | 490 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 72 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 170 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1010 mm | 1023 mm | 1032 mm | 1026 mm |
| Bottom Bracket Drop | 100 mm | 100 mm | 100 mm | 97 mm |
| Standover Height | 656 mm | 695 mm | 722 mm | 742 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
DR. LISA is part of the Kona Dr model. There are 8 bikes that carry this model name. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Wheels size
The DR. LISA 2010 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The DR. LISA has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
