Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 Butted Cromoly
Suspension Fork
Fox 34 Float Performance 120mm Tapered
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus
Front Derailleur
n/a
Shift Levers
Shimano XT
Cassette
Shimano XT 11-42t 11 spd
Crank
34t Wide/Narrow
Bottom Bracket
RaceFace
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Joytech QR15
Rear Hub
Joytech 142x12
Rims
WTB ST i25 TCS
Spokes
Sanvik Stainless 15g fr / 14g rr Black
Tires
Maxxis Tomahawk EXO TR 27.5x2.3"
Brakes
Brakes
Shimano SLX
Brake Levers
Shimano SLX
Disk Rotors
Shimano Deore 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp / Volt Comp 250
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 677 mm | 707 mm | 736 mm | 771 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 102 mm | 101 mm | 102 mm |
| Stack | 595 mm | 609 mm | 618 mm | 632 mm |
| Reach | 406 mm | 431 mm | 456 mm | 486 mm |
| Top Tube Length | 587 mm | 616 mm | 644 mm | 678 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1097 mm | 1128 mm | 1157 mm | 1192 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 669 mm | 714 mm | 754 mm | 804 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Explosif is part of the Kona Explosif model. There are 9 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2016 for 2199$. In conclusion, this bike price is 25.6% lower than the price of the average Trail bike.
Overview of components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Explosif are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Explosif has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
