Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Butted Aluminum
Suspension Fork
RockShox Dart 1 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Acera
Shift Levers
Shimano Acera
Cassette
Shimano HG30 (11-32, 8spd)
Crank
42/34/24
Bottom Bracket
TH
Chain
KMC HG40
Pedals
Xerama SP-500
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
Araya TX 633
Spokes
Stainless 14g
Tires
CST TB68548300 / Kenda K-922 / Innova IA-2113 26x1.95
Brakes
Brakes
Hayes MX4 Mechanical Disc 6"
Brake Levers
Avid FR-5
Cockpit
Stem
Kona Control (8°± ; 14-16=70mm, 18=90mm, 20-22=100mm)
Handlebar
Kona Riser (31.8mm x 660mm Wide)
Grips
Kona Mooseknuckle
Headset
Ritchey LB-Plus
Seat
Saddle
WTB Speed V Sport SE
Seatpost
Kona Thumb
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 356 | 40.7cm | 45.7cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 305 mm | 305 mm | 308 mm | 311 mm | 311 mm |
| Front Center | 619 mm | 632 mm | 654 mm | 672 mm | 692 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 557 mm | 570 mm | 596 mm | 622 mm | 647 mm |
| Seat Tube Angle | 71.6 ° | 71.7 ° | 71.6 ° | 70.6 ° | 70.2 ° |
| Seat Tube Length | 356 mm | 407 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68.2 ° | 68.1 ° | 68.6 ° | 68.6 ° | 68.7 ° |
| Head Tube Length | 90 mm | 90 mm | 110 mm | 150 mm | 165 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1050 mm | 1062 mm | 1085 mm | 1104 mm | 1123 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 35 mm | 32 mm | 32 mm |
| Standover Height | 725 mm | 748 mm | 782 mm | 825 mm | 854 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
FIRE MOUNTAIN is a Kona Fire model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
FIRE MOUNTAIN components
Fork
The FIRE MOUNTAIN comes factory-installed with the RockShox fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the FIRE MOUNTAIN model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona FIRE MOUNTAIN has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
