Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Fork Marzocchi
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Clump 7005 Aluminum
Suspension Fork
Marzocchi 55-RS 140mm w/20mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano Deore (11-32, 8spd)
Crank
Guard/36/24
Bottom Bracket
RPM ISIS DH
Chain
Shimano HG53
Pedals
Kona Jackshit
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
Alex DM-24
Spokes
Stainless 14g
Tires
Maxxis 26x2.35 DHF front/High Roller rear
Brakes
Brakes
Shimano M486 Disc 7"
Brake Levers
Shimano M486 Disc
Cockpit
Stem
Kona OB/DH (6° x 60mm)
Handlebar
Kona OB/DH (31.8mm x 710mm Wide)
Grips
Kona LOG
Headset
FSA Internal ZST-10
Seat
Saddle
WTB Speed V Sport SE
Seatpost
Kona Thumb
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 355 | 40.6cm | 45.7cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 322 mm | 322 mm | 322 mm | 322 mm | 322 mm |
| Front Center | 642 mm | 668 mm | 702 mm | 729 mm | 754 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 561 mm | 587 mm | 620 mm | 646 mm | 671 mm |
| Seat Tube Angle | 71.7 ° | 71.7 ° | 71.7 ° | 71.7 ° | 71.7 ° |
| Seat Tube Length | 355 mm | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1079 mm | 1105 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 766 mm | 749 mm | 777 mm | 807 mm | 835 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
FIVE-O belongs to the Kona Five O model. 3 bikes variations carry this model name so far. You can easily view all of the Kona Five O bikes models from 2010, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Dirt Jump bikes
According to our calculations, the average cost of a Dirt Jump bike that is reliable is 863$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Dirt Jump bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Marzocchi model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the FIVE-O model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The FIVE-O has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
