Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Groupset X7, X5 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Scandium 69 100mm Travel
Suspension Fork
Rock Shox XC 32 TK 100mm
Rear Shock
Rock Shox Monarch RL
Drivetrain
Rear Derailleur
SRAM X7
Front Derailleur
SRAM X7
Shift Levers
SRAM X5
Cassette
SRAM PG1030 11-36t 10 spd
Crank
38/24t
Bottom Bracket
SRAM X5
Chain
SRAM PC1031
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Formula
Rear Hub
Formula 142x12mm
Rims
WTB SX23
Spokes
Stainless 14g
Tires
Maxxis Ikon 29x2.2"
Brakes
Brakes
Avid Elixir 1
Brake Levers
Avid Elixir 1
Disk Rotors
Avid G2 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B-1
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.36 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 675 mm | 690 mm | 700 | 715 mm | 740 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 89 mm | 87 mm | 89 mm | 92 mm | 94 mm |
| Stack | 595 mm | 605 mm | 610 mm | 615 mm | 620 mm |
| Reach | 430 mm | 435 mm | 450 mm | 460 mm | 485 mm |
| Top Tube Length | 590 mm | 600 mm | 615 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1125 mm | 1135 mm | 1150 mm | 1160 mm | 1185 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 760 mm | 790 mm | 805 mm | 820 mm | 850 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
HEI HEI completes the Kona Hei model. 58 bikes variations carry this model name so far. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
HEI HEI components
Rear Shock
The shock that’s installed on this bike is Rock Shox Monarch RL, with a travel distance of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on HEI HEI are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona HEI HEI is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
