Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox
-
Groupset X9 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Scandium 69 Butted Aluminum 100mm travel
Suspension Fork
Fox Float 29 FIT RLC 100mm 15mm TA
Rear Shock
Fox Float RP23 BSD
Drivetrain
Rear Derailleur
SRAM X9 SGS
Front Derailleur
SRAM X9 SGS
Shift Levers
SRAM X9 SGS
Cassette
SRAM PG 1030 11-36 10 spd
Crank
39/26
Bottom Bracket
SRAM X9 SGS
Chain
SRAM PC-1031
Pedals
Shimano M520 Clipless
Wheels
Front Hub
Easton XCT 29er Wheelset
Rear Hub
Easton XCT 29er Wheelset (142x12mm)
Rims
Easton XCT 29er Wheelset
Spokes
Easton XCT 29er Wheelset
Tires
Maxxis Ikon 29x2.2 Kevlar
Brakes
Brakes
Avid Elixir 9
Brake Levers
Avid Elixir 9
Disk Rotors
Avid HS1 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Energy
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Valcon Comp
Seatpost
Kona Primo Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.36 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 675 mm | 690 mm | 700 | 715 mm | 740 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 595 mm | 605 mm | 610 mm | 615 mm | 620 mm |
| Reach | 430 mm | 435 mm | 450 mm | 460 mm | 485 mm |
| Top Tube Length | 590 mm | 600 mm | 615 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1140 mm | 1150 mm | 1165 mm | 1175 mm | 1200 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 760 mm | 790 mm | 805 mm | 820 mm | 850 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Hei Hei 29 Supreme belongs to the Kona Hei model. Kona launched 58 bikes of this model so far. Check out the entire range from 2012 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The Hei Hei 29 Supreme comes factory-installed with the Fox fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox Float RP23 BSD rear shock model, which has a travel of 100mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Hei Hei 29 Supreme 2012 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hei Hei 29 Supreme comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
