Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox SID Ultimate
-
Groupset XX1, X0 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 120mm Travel
Suspension Fork
RockShox Sid Ultimate DebonAir 120mm Tapered 110mm Spacing
Rear Shock
RockShox Sid Luxe Ultimate
Drivetrain
Rear Derailleur
SRAM XX1-Eagle
Front Derailleur
n/a
Shift Levers
SRAM XO-Eagle
Cassette
SRAM XX1-Eagle 10-52t 12spd
Crank
SRAM Descendant DUB Carbon, 34t X-Sync Eagle
Bottom Bracket
SRAM DUB PF92
Chain
SRAM XX1-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
DT Swiss 350 110x15mm
Rear Hub
DT Swiss 350 148x12mm
Rims
WTB KOM Light i27 TCS 2.0
Spokes
Sandvik Stainless Black 2.0/1.8 Butted
Tires
Maxxis Rekon EXO TR 3C 29x2.25"
Brakes
Brakes
SRAM G2 RSC
Brake Levers
SRAM G2 RSC
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
RaceFace Turbine SL 35
Handlebar
RaceFace Next 35
Grips
Kona Key Grip
Headset
FSA No.57E
Seat
Saddle
WTB SL8 Pro
Seatpost
RockShox Reverb w/1x Remote Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.36 mm | 1.3 mm | 1.22 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 695 mm | 724 mm | 751 mm | 788 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 106 mm | 105 mm | 105 mm | 105 mm |
| Stack | 595 mm | 604 mm | 609 mm | 614 mm |
| Reach | 419 mm | 444 mm | 469 mm | 504 mm |
| Top Tube Length | 577 mm | 605 mm | 631 mm | 667 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1127 mm | 1156 mm | 1183 mm | 1220 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 745 mm | 745 mm | 745 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Hei Hei CR/DL belongs to the Kona Hei model. 58 bikes variations carry this model name so far. Take a sneak peek at all Kona Hei bikes models from 2021, by clicking here.
Model range prices
Kona Hei Hei 2021 is the most economical model, with a starting price of 2799$. Kona Hei Hei CR/DL 2021 on the other hand costs 6499$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6499$. Doing a quick comparison, we notice that Hei Hei CR/DL price is 135.3% more expensive than the average cost of a Trail bike.
Hei Hei CR/DL components
Fork
This bike has the RockShox SID Ultimate fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Sid Luxe Ultimate model, with a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Hei Hei CR/DL model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Hei Hei CR/DL comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
