Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 100mm Travel
Suspension Fork
Fox Float 32 CTD Evolution 120mm QR15 Tapered
Rear Shock
Fox Float CTD Evolution
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX
Cassette
Shimano SLX 11-36t 10spd
Crank
24/38t
Bottom Bracket
Shimano SLX Press Fit 92
Chain
KMC X10
Pedals
n/a
Wheels
Front Hub
Shimano SLX QR15
Rear Hub
Shimano SLX 142x12mm
Rims
Stan's ZTR Rapid 25
Spokes
Stainless 15g
Tires
Maxxis Ikon EXO TR 29x2.2"
Brakes
Brakes
Shimano SLX
Brake Levers
Shimano SLX
Disk Rotors
Shimano SLX 180mm (centerlock)
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17" | 18" | 19" | 21" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.4 mm | 1.37 mm | 1.33 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm |
| Front Center | 670 mm | 695 mm | 708 mm | 720 mm | 747 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 97 mm | 98 mm | 97 mm | 97 mm | 98 mm |
| Stack | 586 mm | 596 mm | 600 mm | 605 mm | 615 mm |
| Reach | 397 mm | 419 mm | 430 mm | 441 mm | 464 mm |
| Top Tube Length | 569 mm | 594 mm | 606 mm | 619 mm | 645 mm |
| Seat Tube Angle | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° | 73.8 ° |
| Seat Tube Length | 394 mm | 432 mm | 457 mm | 483 mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 115 mm | 120 mm | 125 mm | 135 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1107 mm | 1132 mm | 1145 mm | 1158 mm | 1184 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm | 21 mm |
| Standover Height | 729 mm | 734 mm | 754 mm | 774 mm | 804 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
HEI HEI DELUXE is part of the Kona Hei model. 58 bikes variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the Fox Float 32 model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float CTD Evolution, with a travel distance of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The wheels on HEI HEI DELUXE are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
