Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Reba
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Scandium 69 100mm Travel
Suspension Fork
Rock Shox Reba RL 29er Tapered 100mm
Rear Shock
Fox Float CTD BV
Drivetrain
Rear Derailleur
SRAM X9
Front Derailleur
SRAM X7
Shift Levers
SRAM X7
Cassette
SRAM PG1030 11-36t 10 spd
Crank
38/24t
Bottom Bracket
SRAM X5
Chain
SRAM PC1031
Pedals
Shimano M520 Clipless
Wheels
Front Hub
Easton XC 29er Wheelset 15mm
Rear Hub
Easton XC 29er Wheelset 142x12mm
Rims
Easton XC 29er Wheelset
Spokes
Easton XC 29er Wheelset
Tires
Maxxis Ikon 29x2.2" Folding
Brakes
Brakes
Avid Elixir 3
Brake Levers
Avid Elixir 3
Disk Rotors
Avid HS1 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.36 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 675 mm | 690 mm | 700 | 715 mm | 740 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 89 mm | 87 mm | 89 mm | 92 mm | 94 mm |
| Stack | 595 mm | 605 mm | 610 mm | 615 mm | 620 mm |
| Reach | 430 mm | 435 mm | 450 mm | 460 mm | 485 mm |
| Top Tube Length | 590 mm | 600 mm | 615 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1125 mm | 1135 mm | 1150 mm | 1160 mm | 1185 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 760 mm | 790 mm | 805 mm | 820 mm | 850 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
HEI HEI DL completes the Kona Hei model. 58 bikes variations carry this model name so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The RockShox Reba is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Kona HEI HEI DL bike has the Fox Float CTD BV model installed, and has a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the HEI HEI DL model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The HEI HEI DL comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
