Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted
Suspension Fork
Fox Float 34 Performance 120mm QR15 Tapered
Rear Shock
Fox Float Performance
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus
Front Derailleur
n/a
Shift Levers
Shimano XT
Cassette
Shimano XT 11-42t 11spd
Crank
34t Narrow/Wide
Bottom Bracket
Shimano Press Fit 92
Chain
KMC X11
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Novatech QR15
Rear Hub
Novatech 142x12mm
Rims
Stan's ZTR Rapid 25
Spokes
Stainless 15g Black
Tires
Maxxis Ardent EXO TR 29x2.25"
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Disk Rotors
Shimano RT66 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp / Volt Comp 250
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.44 mm | 1.38 mm | 1.32 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 673 mm | 701 mm | 730 mm | 763 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 102 mm | 101 mm | 103 mm |
| Stack | 601 mm | 610 mm | 620 mm | 630 mm |
| Reach | 398 mm | 424 mm | 448 mm | 479 mm |
| Top Tube Length | 567 mm | 594 mm | 622 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1104 mm | 1133 mm | 1162 mm | 1195 mm |
| Bottom Bracket Drop | 34 mm | 34 mm | 34 mm | 34 mm |
| Standover Height | 704 mm | 704 mm | 718 mm | 744 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Hei Hei DL Trail completes the Kona Hei model. 58 bikes variations carry this model name so far. Take a sneak peek at all Kona Hei bikes models from 2016, by clicking here.
Model range prices
Kona Hei Hei Trail 2016 is the most affordable bike of this model and has a price of 2499$. On the other hand, Kona Hei Hei DL Trail 2016, is the most expensive and costs 3299$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Kona released this model in 2016, its price was 3299$. In conclusion, this bike price is 19.44% higher than the price of the average Trail bike.
Overview of components
Fork
The Hei Hei DL Trail comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Hei Hei DL Trail bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hei Hei DL Trail comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
