Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox
-
Groupset X0 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 100mm Travel
Suspension Fork
Fox Float CTD Adjust Fit 100mm Tapered
Rear Shock
Fox Float CTD Adjust BV
Drivetrain
Rear Derailleur
SRAM XO Type 2
Front Derailleur
SRAM XO
Shift Levers
SRAM XO
Cassette
SRAM PG1030 11-36t 10 spd
Crank
38/24t
Bottom Bracket
SRAM XO
Chain
SRAM PC1031
Pedals
Shimano M520 Clipless
Wheels
Front Hub
Easton EA90 XC Wheelset 15mm
Rear Hub
Easton EA90 XC Wheelset 142x12mm
Rims
Easton EA90 XC Wheelset
Spokes
Easton EA90 XC Wheelset
Tires
Maxxis Ikon 29x2.2" Folding
Brakes
Brakes
SRAM XO
Brake Levers
SRAM XO
Disk Rotors
Avid HS1 180mm
Cockpit
Stem
RaceFace Turbine
Handlebar
RaceFace Turbine
Grips
Kona Race Light LOG
Headset
FSA No.57E
Seat
Saddle
WTB Volt Race
Seatpost
RaceFace Turbine
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18" | 19" | 21" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.36 mm | 1.34 mm | 1.27 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 665 mm | 690 mm | 700 | 715 mm | 740 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 87 mm | 86 mm | 89 mm | 92 mm | 92 mm |
| Stack | 582 mm | 592 mm | 602 mm | 607 mm | 607 mm |
| Reach | 407 mm | 427 mm | 442 mm | 452 mm | 477 mm |
| Top Tube Length | 567 mm | 592 mm | 607 mm | 617 mm | 647 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 430 mm | 455 mm | 485 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 120 mm | 125 mm | 135 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1102 mm | 1127 mm | 1142 mm | 1152 mm | 1177 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 752 mm | 772 mm | 782 mm | 797 mm | 837 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
HEI HEI SUPREME belongs to the Kona Hei model. There are 58 bikes that carry this model name. You can easily view all of the Kona Hei bikes models from 2013, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
HEI HEI SUPREME components
Fork
This bike has the Fox fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The HEI HEI SUPREME has a rear shock with a travel of 100mm. The model Fox Float CTD Adjust BV is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Kona HEI HEI SUPREME 2013, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona HEI HEI SUPREME has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
