Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox
-
Groupset XTR -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 100mm Travel
Suspension Fork
Fox Float CTD Adjust Fit 100mm Factory Kashima QR15 Tapered
Rear Shock
Fox Float CTD Adjust BV Factory Kashima
Drivetrain
Rear Derailleur
Shimano XTR Shadow Plus
Front Derailleur
Shimano XT
Shift Levers
Shimano XT
Cassette
Shimano SLX 11-36t 10 spd
Crank
24/38t
Bottom Bracket
Shimano XT
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Stan's ZTR Crest Wheelset QR15
Rear Hub
Stan's ZTR Crest Wheelset 142x12mm
Rims
Stan's ZTR Crest Wheelset
Spokes
Stan's ZTR Crest Wheelset
Tires
Maxxis Ikon 29x2.2" Folding
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Disk Rotors
Shimano XT 180mm
Cockpit
Stem
RaceFace Turbine
Handlebar
RaceFace Next
Grips
Kona Race Light LOG
Headset
FSA No.57E
Seat
Saddle
WTB Volt Race
Seatpost
RaceFace Turbine
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17" | 18" | 19" | 21" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.36 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm | 346 mm |
| Front Center | 663 mm | 689 mm | 702 mm | 714 mm | 740 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 87 mm | 72 mm | 91 mm | 89 mm | 88 mm |
| Stack | 583 mm | 592 mm | 602 mm | 607 mm | 611 mm |
| Reach | 409 mm | 431 mm | 443 mm | 453 mm | 476 mm |
| Top Tube Length | 570 mm | 595 mm | 608 mm | 620 mm | 646 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 381 mm | 432 mm | 457 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 120 mm | 125 mm | 135 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1104 mm | 1144 mm | 1142 mm | 1154 mm | 1180 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 753 mm | 773 mm | 784 mm | 798 mm | 840 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
HEI HEI SUPREME belongs to the Kona Hei model. There are 58 bikes that carry this model name. Take a sneak peek at all Kona Hei bikes models from 2014, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
HEI HEI SUPREME components
Fork
The HEI HEI SUPREME comes factory-installed with the Fox fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Kona HEI HEI SUPREME bike has the Fox Float CTD Adjust BV Factory Kashima model installed, and has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the HEI HEI SUPREME bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona HEI HEI SUPREME has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
