Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox
-
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 100mm Travel
Suspension Fork
RockShox RS-1 Solo Air w/ Xlock Full Sprint 120mm Tapered Carbon 110mm Spacing
Rear Shock
RockShox Monarch XX w/ Xlock Full Sprint
Drivetrain
Rear Derailleur
SRAM XX1-Eagle
Front Derailleur
n/a
Shift Levers
SRAM XX1-Eagle
Cassette
SRAM XG-1295-Eagle 10-50t 12spd
Crank
SRAM XX1-Eagle, 34t X-Sync
Bottom Bracket
SRAM GXP PF92
Chain
SRAM XX1-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
SRAM XO Predictive Steering 110x15mm
Rear Hub
Hope Pro4 148x12mm
Rims
RaceFace ARC 31 Carbon
Spokes
DT Super Comp Black
Tires
Maxxis Ardent EXO TR DUAL 29x2.25"
Brakes
Brakes
SRAM Guide RSC
Brake Levers
SRAM Guide RSC
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
RaceFace Turbine R 35
Handlebar
RaceFace Next 35
Grips
Kona Key Grip
Headset
FSA No.57E
Seat
Saddle
WTB SL8 Pro
Seatpost
RockShox Reverb w/1x Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.33 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 670 mm | 700 | 728 mm | 762 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 108 mm | 108 mm | 108 mm | 108 mm |
| Stack | 593 mm | 603 mm | 612 mm | 621 mm |
| Reach | 409 mm | 434 mm | 459 mm | 489 mm |
| Top Tube Length | 567 mm | 594 mm | 622 mm | 654 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1101 mm | 1130 mm | 1159 mm | 1192 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Standover Height | 744 mm | 744 mm | 754 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Hei Hei Supreme completes the Kona Hei model. 58 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Kona Hei Hei AL 2018 has a starting price of 2599$. Kona Hei Hei Supreme 2018 on the other hand is the most expensive at 7999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Kona Hei Hei Supreme price was 7999$. Doing a quick comparison, we notice that Hei Hei Supreme price is 319.9% more expensive than the average cost of a Crosscountry bike.
Hei Hei Supreme components
Fork
The RockShox is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Rear Shock
Kona Hei Hei Supreme bike has the RockShox Monarch XX w/ Xlock Full Sprint model installed, and has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Hei Hei Supreme 2018 bike is equipped with 29″ carbon wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Hei Hei Supreme has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Hei Hei Supreme comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
