Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Rim
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Kona Project Two Aluminum
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 GS
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 12-28 10 spd
Crank
50/39/30
Bottom Bracket
Shimano Tiagra
Chain
Shimano CN5600
Pedals
Wellgo LU-A9
Wheels
Front Hub
Formula
Rear Hub
Shimano Tiagra
Rims
Alex AT-450
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Maxxis Mud Wrestler 700x35C
Brakes
Brakes
Tektro Oryx
Brake Levers
Shimano Tiagra
Disk Rotors
N/A
Cockpit
Stem
Kona XC/Road Stem
Handlebar
Kona Road Bar
Grips
Kona Cork Tape
Headset
FSA No. 10
Seat
Saddle
WTB Valcon Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.45 mm | 1.48 mm | 1.48 mm | 1.47 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 594 mm | 599 mm | 606 mm | 612 mm | 627 mm | 636 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 532 mm | 535 mm | 560 mm | 578 mm | 599 mm | 610 mm |
| Reach | 375 mm | 384 mm | 387 mm | 391 mm | 405 mm | 415 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 567 mm | 587 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 155 mm | 175 mm | 185 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1012 mm | 1018 mm | 1024 mm | 1031 mm | 1046 mm | 1055 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 59 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 758 mm | 767 mm | 799 mm | 824 mm | 849 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Jake is part of the Kona Jake model. 47 bikes variations carry this model name so far. Take a sneak peek at all Kona Jake bikes models from 2012, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Jake components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Jake bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Jake comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
