Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Kona Project Two Aluminum
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 12-30t 10spd
Crank
34/50t
Bottom Bracket
Shimano Tiagra
Chain
KMC X10
Pedals
n/a
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Alex ATD470
Spokes
Sandvik 15g fr / 14g rr
Tires
Challenge Grifo Comp 700x32c
Brakes
Brakes
Hayes CX Comp
Brake Levers
Shimano Tiagra
Disk Rotors
Hayes V-Series 160mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Wet Bar
Grips
Kona Cork Tape
Headset
FSA No.10
Seat
Saddle
Kona CX
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 53cm | 56cm | 59cm | 61cm | 63cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.45 mm | 1.48 mm | 1.48 mm | 1.47 mm | 1.48 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 594 mm | 599 mm | 606 mm | 612 mm | 627 mm | 636 mm | 646 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 77 mm | 73 mm | 71 mm | 67 mm | 65 mm | 61 mm | 61 mm |
| Stack | 532 mm | 534 mm | 560 mm | 578 mm | 599 mm | 610 mm | 624 mm |
| Reach | 375 mm | 384 mm | 387 mm | 391 mm | 405 mm | 415 mm | 421 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 567 mm | 587 mm | 607 mm | 617 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm | 630 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 110 mm | 135 mm | 155 mm | 175 mm | 185 mm | 200 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1012 mm | 1018 mm | 1024 mm | 1031 mm | 1046 mm | 1055 mm | 1065 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 747 mm | 762 mm | 792 mm | 817 mm | 842 mm | 857 mm | 867 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
JAKE belongs to the Kona Jake model. 47 bikes variations carry this model name so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
JAKE components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The JAKE 2015 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The JAKE comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
