Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Kona Carbon Cross
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105 (12-25, 10spd)
Crank
36/46
Bottom Bracket
FSA MegaExo
Chain
Shimano 105
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Mavic Aksium Wheelset
Rear Hub
Mavic Aksium Wheelset
Rims
Mavic Aksium Wheelset
Spokes
Mavic Aksium Wheelset
Tires
Continental SpeedKing Cross 700x35C
Brakes
Brakes
Kore Race
Brake Levers
Shimano 105
Cockpit
Stem
Kona Road (6°±, 47-52=90, 54-56=100, 58-62=115mm)
Handlebar
Kona Road (31.8mm, 47-49=400, 52-54=420, 56-62=440mm Wide)
Grips
Kona Cork Tape
Headset
TH
Seat
Saddle
WTB Rocket V Comp OE
Seatpost
Kona Road
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 293 mm | 293 mm | 293 mm | 293 mm | 293 mm | 293 mm | 293 mm | 293 mm |
| Front Center | 592 mm | 591 mm | 594 mm | 600 mm | 605 mm | 615 mm | 625 mm | 645 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 525 mm | 535 mm | 546 mm | 556 mm | 566 mm | 581 mm | 596 mm | 615 mm |
| Seat Tube Angle | 73.7 ° | 73 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm |
| Head Tube Angle | 69.4 ° | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 90 mm | 90 mm | 115 mm | 135 mm | 150 mm | 160 mm | 180 mm | 195 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1022 mm | 1022 mm | 1024 mm | 1030 mm | 1036 mm | 1046 mm | 1055 mm | 1075 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Standover Height | 754 mm | 762 mm | 791 mm | 811 mm | 826 mm | 841 mm | 859 mm | 876 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
JAKE THE SNAKE completes the Kona Jake model. Kona released 47 bikes variations of this model so far. You can easily view all of the Kona Jake bikes models from 2010, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the JAKE THE SNAKE bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The JAKE THE SNAKE has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
