Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Apex, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
48cm
147cm - 160cm
50cm
152cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted
Suspension Fork
Kona Carbon Cross
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Apex
Front Derailleur
n/a
Shift Levers
SRAM Apex
Cassette
SRAM PG1130 11-32t 11spd
Crank
FSA Gossamer Compact 1x MegaExo, 40t
Bottom Bracket
FSA 6200 68mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB ST i19 TCS
Spokes
Stainless Black 14g
Tires
Maxxis All Terrane EXO TR DUAL 700x33c
Brakes
Brakes
TRP HY/RD C
Brake Levers
SRAM Apex
Disk Rotors
TRP 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 282 mm | 282 mm | 284 mm | 284 mm |
| Front Center | 592 mm | 604 mm | 610 mm | 622 mm | 630 mm | 641 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 77 mm | 77 mm | 73 mm | 74 mm | 71 mm | 71 mm |
| Stack | 520 mm | 540 mm | 555 mm | 575 mm | 595 mm | 615 mm |
| Reach | 370 mm | 375 mm | 380 mm | 385 mm | 390 mm | 395 mm |
| Top Tube Length | 511 mm | 526 mm | 541 mm | 557 mm | 573 mm | 591 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 100.6 mm | 121.8 mm | 137.9 mm | 159.1 mm | 180.2 mm | 201.4 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1002 mm | 1014 mm | 1021 mm | 1033 mm | 1040 mm | 1052 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 68 mm | 68 mm |
| Standover Height | 742 mm | 759 mm | 782 mm | 797 mm | 817 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 160 cm | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
Model Overview
Jake the Snake belongs to the Kona Jake model. 47 bikes variations carry this model name so far. Take a sneak peek at all Kona Jake bikes models from 2020, by clicking here.
Model range prices
Kona Jake the Snake 2020 is the cheapest bike model and costs 1499$. Kona Major Jake 2020 is the most expensive one and costs 2999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Cyclocross bikes average price
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, even though the average price of a Cyclocross bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Kona released this model in 2020, its price was 1499$. In conclusion, this bike price is 34.22% lower than the price of the average Cyclocross bike.
Jake the Snake components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Kona Jake the Snake 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Jake the Snake has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
