Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
RockShox XC 32 TK 100mm Tapered
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano Deore 11-36t 10 spd
Crank
24/32/42t
Bottom Bracket
FSA BB 1000
Chain
KMC X10
Chain Guide
n/a
Pedals
Wellgo Platform
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
WTB SX19
Spokes
Stainless 14g
Tires
Maxxis Ikon 29x2.2"
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Double Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.54 mm | 1.52 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 651 mm | 677 mm | 690 mm | 718 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 622 mm | 631 mm | 650 | 669 mm |
| Reach | 391 mm | 414 mm | 421 mm | 441 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 135 mm | 155 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1082 mm | 1108 mm | 1122 mm | 1149 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 783 mm | 809 mm | 840 mm | 873 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
KAHUNA is part of the Kona Kahuna model. 22 bikes variations carry this model name so far. You can easily view all of the Kona Kahuna bikes models from 2014, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the RockShox model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The KAHUNA 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
