Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Fork RockShox Recon Gold RL -
Groupset X7, X5 -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Rock Shox Recon Gold TK Solo Air 20mm TA
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X7 SGS
Front Derailleur
SRAM X5
Shift Levers
SRAM X5
Cassette
SRAM PG-1030 11-36 10 spd
Crank
44/33/22
Bottom Bracket
SRAM X5
Chain
SRAM PC-1031
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Formula Disc
Rear Hub
Formula Disc
Rims
WTB SpeeDisc All Mountain
Spokes
Sandvik Stainless 14g
Tires
Maxxis Ignitor 29x2.1
Brakes
Brakes
Avid Elixir 3
Brake Levers
Avid Elixir 3
Disk Rotors
Avid HS1 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Energy
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Valcon Sport SE
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.51 mm | 1.54 mm | 1.55 mm | 1.53 mm |
| Bottom Bracket Height | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 665 mm | 675 mm | 680 mm | 680 mm | 695 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 620 mm | 635 mm | 645 mm | 660 mm | 680 mm |
| Reach | 400 mm | 420 mm | 420 mm | 425 mm | 445 mm |
| Top Tube Length | 575 mm | 600 mm | 615 mm | 625 mm | 655 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 68.5 ° | 70 ° | 70 ° | 71 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1105 mm | 1120 mm | 1120 mm | 1120 mm | 1135 mm |
| Bottom Bracket Drop | 69 mm | 64 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 785 mm | 820 mm | 835 mm | 855 mm | 890 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Kahuna Deluxe is part of the Kona Kahuna model. Kona released 22 bikes variations of this model so far. Check out the entire range from 2012 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Kahuna Deluxe components
Fork
The Kahuna Deluxe comes factory-installed with the RockShox Recon Gold RL fork. This has a travel range of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Kahuna Deluxe bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Kahuna Deluxe is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
