Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Scandium 69
Suspension Fork
RockShox Recon Gold TK Solo Air 100mm Tapered QR15
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano XT
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50 11-36t 10spd
Crank
24/38t
Bottom Bracket
Shimano Deore
Chain
KMC X10
Pedals
Wellgo Platform
Wheels
Front Hub
Shimano Deore QR15
Rear Hub
Shimano Deore
Rims
WTB ST i19 TCS
Spokes
Stainless 14g
Tires
Maxxis Ikon EXO TR 29x2.2"
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano Deore 180mm (centerlock)
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport SE
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.51 mm | 1.49 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 650 | 675 mm | 690 mm | 722 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 86 mm | 86 mm | 87 mm | 86 mm |
| Stack | 618 mm | 627 mm | 646 mm | 665 mm |
| Reach | 391 mm | 413 mm | 427 mm | 446 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 645 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 135 mm | 155 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1082 mm | 1107 mm | 1127 mm | 1154 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 738 mm | 768 mm | 803 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
KAHUNA DELUXE is a Kona Kahuna model. There are 22 bikes that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The KAHUNA DELUXE comes factory-installed with the RockShox Recon Gold RL fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The KAHUNA DELUXE 2015 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
