Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
RockShox Recon SL Solo 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50 (11-32, 9spd)
Crank
44/32/22
Bottom Bracket
FSA MegaExo
Chain
KMC HG53
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M525 Disc
Rims
Sun DS2-XC
Spokes
Sandvik Stainless 15g
Tires
Maxxis Aspen 26 x 2.1 Kevlar
Brakes
Brakes
Shimano 575 Disc 7" fr / 6" rr
Brake Levers
Shimano 575 Disc
Cockpit
Stem
Kona XC/BC Stem (6°± ; 14-16=75mm, 17-19=90mm, 20-22=105mm)
Handlebar
Kona XC/BC Riser (31.8mm x 660mm Wide)
Grips
Kona Race Light
Headset
TH
Seat
Saddle
WTB Rocket V Comp
Seatpost
Kona XC/BC
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 356 | 40.6cm | 43.2cm | 45.7cm | 48.3cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 310 mm | 310 mm | 313 mm | 313 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 619 mm | 632 mm | 642 mm | 654 mm | 658 mm | 672 mm | 693 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 557 mm | 570 mm | 583 mm | 596 mm | 610 mm | 622 mm | 647 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 70.5 ° | 70.5 ° | 70 ° |
| Seat Tube Length | 356 mm | 406 mm | 432 mm | 457 mm | 483 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 120 mm | 140 mm | 160 mm | 175 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1050 mm | 1063 mm | 1073 mm | 1085 mm | 1090 mm | 1103 mm | 1124 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 30 mm | 30 mm | 27 mm | 27 mm | 27 mm |
| Standover Height | 732 mm | 754 mm | 777 mm | 788 mm | 810 mm | 830 mm | 859 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
KULA belongs to the Kona Kula model. 16 bikes variations carry this model name so far. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the KULA bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
